Battery Pack Leds - HP 381513-B21 - Smart Array P800 Controller RAID User Manual

LED ID Color
6 Green
7 Green
8 Green
9 Green
10 Green
Gas pedal LED
status
Off
Blinking
On steadily
On steadily

Battery pack LEDs

Item ID Color
1 Green
Name
CR507: Activity
CR506: Command Outstanding
CR505: Controller Heartbeat
CR504: Gas Pedal
CR503: Idle Task
Idle task LED Controller CPU activity level
status
Blinking 0–25%
Off 25–50%
Off 50–75%
On steadily 75–100%
Description
System Power LED. This LED glows steadily when the
system is powered up and 12 V system power is
available. This power supply is used to maintain the
battery charge and provide supplementary power to the
cache microcontroller.
Comments
Port 3I is active.
The controller is working on a command from the
host driver.
When the controller is in good health, this LED
flashes every two seconds.
This LED, together with the Idle Task LED (next
item), indicates the amount of controller CPU
activity. For details, see the following table.
This LED, together with the Gas Pedal LED
(previous item), indicates the amount of controller
CPU activity. For details, see the following table.
Diagnosing array problems 44
