UNVENTED (VENT-FREE) UNIVERSAL FIREBOX
SAFETY INFORMATION AND INSTALLATION MANUAL
shown with optional cabinet
mantel with base
CGFB32CA CIRCULATING LOUVERED MODEL
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
FoR use oNly WIth A lIsted GAs-FIRed uNveNted
decoRAtIve Room heAteR Not to exceed 40,000
Btu/Hr. Do not BuilD a wooD fire.
Carefully review the instructions supplied with the
decorative type unvented room heater for the minimum
fireplace size requirement.
do Not INstAll AN ApplIANce IN thIs FIRebox
uNless thIs FIRebox meets the mINImum dImeN-
sions requireD for tHe installation.
this firebox has been tested and approved by Csa
under ansi Z21.91 for use with any ansi Z21.11.2 ap-
proved gas logs.
installer: leave this manual with the appliance.
ConsuMer: retain this manual for future reference.
For more information, visit www.desatech.com
Advertisement
Table of Contents
Related Manuals for Comfort Glow CGFB32CA
Summary of Contents for Comfort Glow CGFB32CA
- Page 1 SAFETY INFORMATION AND INSTALLATION MANUAL shown with optional cabinet mantel with base CGFB32CA CIRCULATING LOUVERED MODEL WARNING: If the information in this manual is not fol- lowed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
