Comfort Glow 25-900-001 Installation And Operating Instructions Manual
Comfort Glow 25-900-001 Installation And Operating Instructions Manual

Comfort Glow 25-900-001 Installation And Operating Instructions Manual

Electric fireplace insert

Advertisement

HOMEOWNER'S INSTALLATION AND OPERATING INSTRUCTIONS
C
US
Questions, problems, missing parts? Before returning to your retailer, call our
20-10-213

ELECTRIC FIREPLACE INSERT

IMPORTANT INSTRUCTIONS
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY,
AN ELECTRICAL SHOCK OR FIRE MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
customer service department at 1-800-776-9425,
8:30 a.m. –5:00 p.m. EST, Monday – Friday.
MODEL #25-900-001
WARNING!
1
Français p. 19
Español p. 39
For installation with
Comfort Glow
Fireplace Mantel
Rev.4/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 25-900-001 and is the answer not in the manual?

Questions and answers

Sharon Sedore
February 1, 2025

Where can I order this insert

Summary of Contents for Comfort Glow 25-900-001

  • Page 1: Electric Fireplace Insert

    HOMEOWNER’S INSTALLATION AND OPERATING INSTRUCTIONS ELECTRIC FIREPLACE INSERT MODEL #25-900-001 Français p. 19 Español p. 39 For installation with Comfort Glow Fireplace Mantel IMPORTANT INSTRUCTIONS PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 2: Table Of Contents

    Replacement Parts List ........................17 Thank you and congratulations on your purchase of a Comfort Glow electric fireplace. IMPORTANT: Read all instructions and warnings carefully before starting Installation. Failure to follow these instructions may result in a possible electric shock, injury to persons, fire hazard and will void the warranty.
  • Page 3 SAFETY INFORMATION SAVE THESE INSTRUCTIONS Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-800-776-9425, 8:30 a.m. –5:00 p.m. EST. – Friday. Read all instructions before using this appliance.
  • Page 4: Safety Information

    SAFETY INFORMATION DANGER Electrical Connection A 15-Amp, 120-Volt, 60 Hz circuit with a properly grounded outlet is required. Preferably, the fireplace will be on a dedicated circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow when the heater is in operation. The unit comes standard with a 6 ft. (1.8 m) long three wire cord, exiting the right side of the fireplace. Plan the installation to avoid the use of an extension cord.
  • Page 5 SAFETY INFORMATION Remote Control This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Industry Canada ICES-003. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, might cause harmful interference to radio communications.
  • Page 6 INSTALLATION INSTRUCTIONS Fireplace Dimensions Specifications 120 V AC Voltage 60Hz Frequency Heater Rating 1350W Max. Amps Width 24-1/4 in. (616 mm) Depth 9-13/32 in. (239 mm) Height 20-1/4 in. (514 mm)
  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Package Contents JY-3B PART DESCRIPTION QUANTITY Mounting Bracket Kit Screw (ST4) Infrared Remote Control...
  • Page 8 INSTALLATION INSTRUCTIONS The Fireplace should be located in an area: • Out of direct sunlight • Not susceptible to moisture • Away from uninsulated outside wall • At least 3 ft. (.9 m) from drapery, furniture and other combustibles Clearance to Combustibles Sides 2-27/64 in.
  • Page 9 INSTALLATION INSTRUCTIONS 1. Place the assembled mantel near a 15-amp, 120-volt grounded electric outlet. Read all instructions before using this appliance. 2. Place the insert directly in front of the mantel opening. 3. Carefully lift the insert through the center opening in the front of the fireplace. The bottom of the insert has two foam rubber strips to prevent scratching of the hearth base. Slide the insert back through the opening until the metal trim makes contact with the front of the mantel.
  • Page 10 OPERATING INSTRUCTION The fireplace control functions can be accessed in two (2) ways: • Using the touchpad control panel, located in the upper right-hand corner of the fireplace behind the sliding control panel cover. • Using the multifunction remote control unit. The fireplace features conveniently separate controls for flame effect and for heater control. This allows you to operate the unit in two (2) different modes: • As a full-featured fireplace - both flame effect and heater are on.This mode allows you to enjoy the look of the fire along with the heat output of a heater. • As a visual effect - only the flame effect is on, the heater is off. We recommend this mode for warm weather application, when you want the ambiance of a fire, without any heat output.
  • Page 11 OPERATING INSTRUCTION Fahrenheit/Celsius Display: This button displays F (Fahrenheit) or C (Celsius) depending on how the temperature mode is set. When the fireplace is first turned on, the Fahrenheit (F) temperature will be displayed. To switch from Fahrenheit to Celsius, or vise-versa, when HEATER is ON, hold HEATER CONTROL button for 10 seconds. The fireplace will remember the last temperature mode setting, and in later use, the display will start at that setting, unless power to the unit has been interrupted. Temperature/Timer Display This LED display shows the set point for the temperature and timer functions.
  • Page 12 OPERATING INSTRUCTION IMPORTANT: Under normal operation, when power is interrupted from either an outage or from unplugging unit from wall while still in operation, error code “EC” may appear on the LCD control panel and the unit will cease operation. In order to reset, unplug the unit for 10 minutes, then plug back in for normal operation in accordance with the Use and Care Guide.
  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE Before attempting ANY maintenance: 1. Turn off power to the unit. 2. Unplug the power cord from outlet. 3. Let fireplace cool if it has been operating. Glass Information: 1. Under no circumstances should this product be operated with broken glass. 2. Do not strike or slam the glass. 3.
  • Page 14: Electric Wiring Diagram

    ELECTRIC WIRING DIAGRAM Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. CIRCUIT DIAGRAM WARNING: Disconnect power before servicing. DANGER Disconnect power before servicing. Any electrical re-wiring of this appliance must be done by a qualified electrician. This wiring must be done in accordance with local codes and/or in Canada with the current CSA C22.1 Canadian Electrical Code, and for US installations, the National Electrical Code ANSI/NFPA NO 70.
  • Page 15: Troubleshooting

    TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-800-776-9425, 8:30 a.m. –5:00 p.m. EST, Monday – Friday. Problem Possible Cause Corrective Action 1. The fireplace is not 1. Make sure the fireplace is plugged in Fireplace does to a standard 120V outlet. not operate; the plugged in. ON/OFF power 2.
  • Page 16: Warranty

    WARRANTY The manufacturer warrants that your new electric fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. This electric fireplace must be installed and operated at all times in accordance with the instructions furnished with the product. Any alteration, willful abuse, accident, or misuse of the product shall nullify this warranty. 2.
  • Page 17: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, please call customer service at 1-800-776-9425, 8:30 a.m. –5:00 p.m. EST, Monday – Friday. Ref. Description 25-900-001 Top panel EF23350AC Left side panel assembly EF23106AC Right side panel assembly EF23107AC EF23354AC Back panel Trim assembly...
  • Page 18 Printed in China...
  • Page 19: Important Instructions

    SARDONIA COMPACT FIREPLACE MODEL #EF5538 Español p. 12 Francais p. 23 IMPORTANT INSTRUCTIONS PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 20 TABLE OF CONTENTS Safety Information .........................3-4 Package Contents .........................5-6 Operating Instructions ........................7 Care and Maintenance ........................8 Electric Wiring Diagram ........................9 Troubleshooting ..........................10 Warranty ............................11 IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, injury to persons, fire hazard and will void the warranty.
  • Page 21 SAFETY INFORMATION SAVE THESE INSTRUCTIONS Please read and understand this entire manual before attempting to assemble, operate or install the product. Read all instructions before using this appliance. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance.
  • Page 22: Safety Information

    SAFETY INFORMATION DANGER Electrical Connection A 15 Amp, 120 Volt, 60 Hz circuit with a properly grounded outlet is required. Preferably, the fireplace will be on a dedicated circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow when the heater is in operation. The unit comes standard with a 6 ft. (1.8 m) long, three-wire cord, exiting the right side of the fireplace. Plan the installation to avoid the use of an extension cord.
  • Page 23: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY A Electric Heater/Wood Mantel...
  • Page 24 PACKAGE CONTENTS Fireplace Dimensions Ref. EF5538 10.88 in. (276.4 mm) Clearance to Combustibles 38 in. (965.2 mm) Sides 2-27/64 in. (61.5 mm) 33 in. (838.2 mm) Floor 0 in. (0 mm) TECHNICAL SPECIFICATIONS 2 in. (51 mm) VOLTAGE 120V AC FREQUENCY 60HZ Front 36 in.
  • Page 25: Operating Instructions

    OPERATING INSTRUCTIONS Read All Instructions Before Use Check that the heater outlet grill is not covered or obstructed in anyway, and make sure the power to the unit is switched on. NOTE: When the heat function is used for the first time, a slight odor may be present. This is normal and should not occur again unless the heater is not used for an extended period of time. Control Panel The control panel is located inside the lower right door on the front panel.
  • Page 26: Care And Maintenance

    CARE AND MAINTENANCE Cleaning Always turn the heater OFF and unplug the power cord from the outlet before cleaning. Use a vacu- um or duster to remove dust and dirt from the heater and vent areas. To maintain the finish, clean with a soft, slightly damp cloth and buff with a dry cloth.
  • Page 27: Electric Wiring Diagram

    ELECTRIC WIRING DIAGRAM Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. CIRCUIT DIAGRAM DANGER Disconnect power before servicing. Any electrical re-wiring of this appliance must be done by a qualified electrician. This wiring must be done in accordance with local codes and/or in Canada with the current CSA C22.1 Canadian Electrical Code, and for US installations, the National Electrical Code ANSI/NFPA NO 70.
  • Page 28: Troubleshooting

    TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-800-776-9425, 8:30 a.m. –5:00 p.m. EST, Monday – Friday. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Fireplace does 1. The fireplace is not 1. Make sure the fireplace is plugged in not operate. plugged in. to a standard 120V outlet. 2. A circuit breaker is tripped 2.
  • Page 29: Warranty

    WARRANTY The manufacturer warrants that your new electric fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Variations in actual wood color and finishes which may result from natural characteristics of the wood, such as grain patterns, mineral streaks and the like, are not considered defects. As wood continues to move and age you may notice these slight differences in color, even on different parts of any individual unit.

Table of Contents
