USER SECTION
System Components
ISDR1 Door Strike Release Module
This optional module provides a connection point for a separate door strike release unit,
making it possible to unlock the door from any keypad.
3
ISDR1 Door Strike Release Module
ISSP ComPoint Speaker
This optional in-wall speaker sits beside a
Basic or Advanced keypad in a room without
multiroom audio system speakers. It can also
be used in every room when ComPoint is used
as a stand-alone system.
8
1
1
OUTPUT CONNECTOR – Punch-down connector
for CAT-5 cable to an ISK3 Door Station
2
INPUT CONNECTOR – Punch-down connector for
CAT-5 cable from the ISH1 hub
3
RELAY OUTPUT CONNECTOR – Removable con-
nector for a door strike release, gate actuator,
or other device
2
ISSP ComPoint Speaker
