Summarization of Contents
SONO-DIS
1 General Notices
Covers intended use, accumulator charging, and ambient conditions for the handheld device.
2 Control Elements
Details the probe/charger connection and the function of the SONO-DIS control keys and display.
3 Initial Commissioning
Guides through safety, scope check, accumulator charging, and sensor connection for first-time use.
4 Operation
Explains general operation buttons, symbols, messages, and power controls for the device.
5 Technical Data SONO-DIS
Lists technical specifications like dimensions, power consumption, and operating temperature.
SONO-DIS with SONO-WZ
1 General Settings
Configures device language, modes, display settings, and probe information for SONO-WZ.
2 Concrete Specific Base Parameters
Sets density, CHAR, and G-Set parameters crucial for concrete moisture measurements.
3 Standard Measurement mode „Average"
Explains conducting water content measurements using the device's average mode.
4 In 5 steps to a successful measurement
Provides a step-by-step guide for accurate measurements with the SONO-WZ probe.
SONO-DIS with SONO-M1
1 General Settings
Configures device modes, language, calibration, and display settings for SONO-M1.
2 Measurment Volume | Probe Dimensions
Details the effective measurement volume and physical dimensions of the SONO-M1 probe.
3 How to use the SONO-DIS kit
Guides on measuring sand, gravel piles, and laboratory samples with the SONO-DIS kit.
4 Technical Data SONO-M1 Probe
Lists electrical, measurement, and physical specifications for the SONO-M1 probe.
5 Exchange of the Probe Rods
Provides step-by-step instructions for replacing the probe rods on the device.
6 Safety Notes
Highlights essential safety precautions for operating the SONO-DIS system and probes.
7 Notizen
Blank page intended for user notes.
