SCOTT GENIUS
USER MANUAL
W W W . S C O T T - S P O R T S . C O M
Advertisement
Table of Contents
Related Manuals for Scott S / 700
Summary of Contents for Scott S / 700
- Page 1 SCOTT GENIUS USER MANUAL All rights reserved © 2017 SCOTT Sports SA Distribution: SSG (Europe) Distribution Center SA, P.E.D. Zone C1, Rue du Kiell 60, 6790 Aubange, Belgium v7.0/03072017 W W W . S C O T T - S P O R T S . C O M WWW.SCOTT-SPORTS.COM...
-
Page 2: Table Of Contents
Basic Set-Up of Shock & Forks Rebound Shock Set-Up Replaceable Rear Dropout The SCOTT Genius should be adjusted exactly to the individual rider to achieve maximum saftey and fun while riding. Pivot Maintenance SCOTT recommends that all adjustments be carried out by Wheels your local authorized SCOTT dealer. -
Page 3: Genius Concept
Please note: Tire sizes often vary from brand to brand. Ensure the tire clearance is adequate when replacing your tires! S / 900 S / 700 M / 900 M / 700 L / 900... -
Page 4: Twinloc
Recommended tools for the shock setup: cranks/wheels/dropouts/forks differ from traditional cycle parts. Always consult your authorized SCOTT dealer for advice on replacing or repairing any part of your SCOTT bike! The SAG tool that came with your bike. A shock pump with a dial up to 20bars/300psi with a special air valve connector (not supplied with this bike), this will help stop air from escaping while removing the pump •... -
Page 5: Sag
• REBOUND SHOCK SET-UP Your SCOTT bike will be supplied with a SAG tool to help set up your bikes suspension, these “Rebound” describes the speed the shock returns back to its original length after absorbing SAG tools can be easily clipped on the shock body and fork dust seal. -
Page 6: Replaceable Rear Dropout
On SCOTT Genius models for 2018 the rear derailleur hanger is replaceable, depending on your model of SCOTT Genius there are 5 different hangers available, 2 for carbon swingarms and 3 alloy swingarms, these parts can be seen below, please consult your SCOTT dealer for information on the correct part. -
Page 7: Pivot Maintenance
• WHEELS As with all parts on your SCOTT bike please ensure all bolts are set to the correct torque and threadloc used where applicable/ geo chip bolt 10 N/M and 242 (medium strength) The SCOTT Genius frame is incredibly versatile with the option to change your wheel size threadloc. - Page 8 Image is shown with livewire and Di2 installed. Shifter cable If you wish to change or replace the headtube cableguide set on your SCOTT Genius this kit can be ordered from your local SCOTT dealer. Brake cable SCOTT part number: 266587 and consists of:...
-
Page 9: Bb Standards/Fd Mounting Details
The SCOTT Genius has a Press fit PF92 bottom bracket with an inner diameter of 41mm, this need to be supported is a press fit system and special tools are required for removal and refitting, please contact with a rubber cover and your SCOTT dealer for assistance. -
Page 10: Guarantee On Scott Bikes
To make a claim under this limited warranty, you must notify SCOTT of the claimed defect within the warranty period and timely return the Product to SCOTT at your expense for inspection.
