Summary of Contents for Scott SPARK MY22
- Page 1 SPARK MY22 MANUAL...
-
Page 2: Technical Data
Technical Data: Seatpost: 31.6mm Seatpost Clamp: 34.9mm Rear 120mm Travel: Front: RC 120mm Non RC 130mm Shock Length: 165mm Shock Stroke: 45mm Hardware M/Frame: Trunnion 20mm Bush x Hardware Linkage: 10mm Bolt BB Housing: 92x41mm Chainring Max: 38 Tooth Chain Line: 55mm Tyre Width Max: 2.4 Inches... - Page 3 MY22 RC // +0,6° head cup // 120mm fork Small Medium Large X/Large HEAD TUBE ANGLE 67.2° 67.2° 67.2° 67.2° HEAD TUBE LENGTH 90 mm 90 mm 105.0 mm 115.0 mm TOP TUBE HORIZONTAL 562 mm 590 mm 614 mm 642 mm STANDOVER HEIGHT 758 mm...
- Page 4 PLEASE TAKE NOTE OF THE BELOW ICONS THROUGHOUT THIS MANUAL FOR SAFE PRACTISE. EASY TECHNICAL STEP IMPORTANT TECHNICAL STEP NO GREASE WITH GREASE THREADLOC BEARING FIT WARNING/CAUTION TORQUE CHECK ENGLISH / SPARK TECH MANUAL...
- Page 5 Hangers & Axles: The Spark has only one rear hanger, this is the SRAM UDH. This is available from your SRAM agent, also available via an Authorised Scott Dealer. 286000 - SCO Dropout Sram UDH 21 The UDH must be assembled without grease to a torque of 25Nm...
- Page 6 The new rear axle is specific for the Spark and contains a “plug in“ tool containing T30/T25 and M6 Hex key: 290016 - SCO Axle RWS Rear 148x12 Spark Plug 22 The Axle must be assembled with grease, and torqued to 10Nm.
- Page 7 Rear Brake Mounting: The brake calliper mount is a standard post mount with a specific adaptor for the Spark, this is available in 160 and 180mm only. (No live valve option). 290010 - SCO Brake Mount Spark 22 The 180mm mount will need conical washers, as in previous years. ENGLISH / SPARK TECH MANUAL...
- Page 8 Chain Protectors: The Chainstay Protectors will come in two options: 290017 - SCO Chainsuck Protector Spark 22 288539 - SCO CS/SS Protector Glue Spark CB 22 288540 - SCO CS/SS Protector Glue Spark AL 22 ENGLISH / SPARK TECH MANUAL...
- Page 9 Maximum Seatpost Insertion: Please observe the maximum seatpost insertion, there is no stopper inside the frame. This is size specific: Small: 150mm Medium: 175mm Large: 225mm XLarge: 275mm ENGLISH / SPARK TECH MANUAL...
- Page 10 Headset: The Spark headset is unique, it has several set up variables: 288251 - SYN Headset ZS56/28.6 - ZS56/40 MTB This will be bearing, crown race, and compression ring! 290060 - SCO Headset Cup Kit Spark 22 This will include two cups of 0 degree & 0.6 degree. Size Specific Do not use a standard Headset Removal Tool to remove the cups.
- Page 11 Headset indication and orientation, it is important to have the headset installed correctly depending on the setup. There are two types, 0° and 0.6°, these can be identified from the stamp on the inner surface of the headset cup. For 0.6° this can be installed at + or – but it is essential that the angle indication markers on the headset are set opposite to each other, top facing forward and bottom facing backwards (or vice versa).
- Page 12 The headset assembly must follow the below no matter which bar/stem system is being used. ENGLISH / SPARK TECH MANUAL...
- Page 13 There are three separate Stem Spacer Kits & one Headset Spacers Kit: 290059 - SCO Stem Spacer/top cap SY MTB XC 22 290057 - SCO Stem Spacer/top cap SY MTB Combo 22 290058 - SCO Stem Spacer/top cap SY MTB DC 22 The Headset Spacer Kit will contain 3 x 5mm, 2 x 10mm, 1 x 20mm Spacers: 290056 SCO - Headset Spacer Kit IC MTB 22 ENGLISH / SPARK TECH MANUAL...
- Page 14 Cable Guides & Covers: The MY22 Spark’s cable routing is all internal, the follow guides & covers are available: 290021 - SCO Cable/Shock DT Cover Spark 22 290054 - SCO Handlebar Cableguide Kit MTB IC 22 290020 - SCO Cableguide & BB Cover Spark 22 ENGLISH / SPARK TECH MANUAL...
- Page 15 Basic Shock Pump Set -Up: A Scott Shock pump has a special valve head and the following steps should be followed to make sure the correct pressure is applied. Please note the air will flow into the hose and gauge when counterchecking the air pressure.
- Page 16 Please follow the below steps depending on which shock pump type you have. 5 step or second 3 step. Attach the upper shock pump head to the shock valve, making sure the lower part of the pump head stays in the lower position. Do not screw upwards together.
- Page 17 Sag: Make sure before any adjustment is made that your shock and forks are in the open position. To do this press the twinloc upper silver lever twice. 2. With the shock pump attached to the rear shock valve, pump your desired pressure into the shock.
- Page 18 SCOTT dealer for any assistance you need, failure to do this may affect your warranty ENGLISH / SPARK TECH MANUAL...
- Page 19 SHOCK REMOVAL STEPS: Please take note of the info on each bolt: (tool type & size, plus torque) Please remove the rear wheel and Remove the lower shock cover. crankset before starting this process. Disconnect the seatstay / linkage pivot, removing the bearing spacers. ENGLISH / SPARK TECH MANUAL...
- Page 20 Remove the lower shock bolts and Remove the rubber shock bolt cover. disconnect the TC Cable. Rotate the linkage upwards until the upper shock bolt is visible in the shock window. Remove the shock from the bike. When re-installing the shock please make sure all bolts are correctly torqued and threadloc is used.
-
Page 21: Cable Routing
CABLE ROUTING: Rear Derailleur Cable Routing Rear Brake Hose Routing ENGLISH / SPARK TECH MANUAL... - Page 22 Dropper Seatpost Routing Twinloc Routing ENGLISH / SPARK TECH MANUAL...
-
Page 23: Guarantee On Scott Bikes
What will SCOTT do in the event of a guarantee case? SCOTT will replace the defective product with a product of a quality or nature and similar level, will repair or refund the purchase price (after presentation of the proof of purchase of the product), in its sole discretion. - Page 24 SCOTT Sports SA reserves the right to change the content of this techbook, particularly colors, materials and specifications, at any time without prior notice. Any liability shall be exempted. Products shown may not be available in all regions, please check with your local SCOTT retailer for availability. EDITOR...
