- Page 1 BIKE OWNER’S MANUAL 2015 All rights reserved © 2014 SCOTT Sports SA SCOTT Sports SA | 17 Route du Crochet | 1762 Givisiez | Switzerland Distribution: SSG (Europe) Distribution Center SA P.E.D Zone C1, Rue Du Kiell 60 | 6790 Aubange | Belgium...
-
Page 2: Table Of Contents
Scale Carbon Concept ........ -
Page 3: Scale Carbon Concept
SCOTT-ODLO Racing Team searching for one of the lightest cross country racing frames in the market. SCOTT’s focus was not only on creating a lightweight frame, but one that was also a stiff and easy to handle racing frame. SCALE 700 A HEAD TUBE ANGLE 69.0 °... -
Page 4: Bb Standards/Fd Mounting Details
PF BB 92 has a housing width of 92mm (Scale 700) or 89.5mm plus a 2.5mm additional washer (Scale 900) with an inner diameter for the cartridges of 41mm. HEADSET OPTIONS Scale Carbon features a tapered headset and fork steerer system to match with semi-integrated headsets of the “50-61”mm range. Scale 700 (27.05”) FD Scale 900 (29”) FD... -
Page 5: Bb Cable Guide/Cable Routing
Scale Carbon features also an internal cable routing for front and rear derailleur. 1. Remove the clip-in BB Guide in the BB housing A special BB Cable Guide was developed for Scale Carbon which is available as a spare part at the SCOTT distribution with article number 2. -
Page 6: Replaceable Rear Derailleur Hanger
We recommend using front forks with distance of 487mm/19.2” for Scale 700 and If you want to use another RWS standard SCOTT can also offer the following as after-market parts for specific wheelsets via the SCOTT distribution: 506mm/19.9” for Scale 900... -
Page 7: Warranty
Doing so SCOTT warrants its frames and swingarms for five years (subject to compliance with maintenance ranges, see below) and SCOTT forks (provided it is a fork of SCOTT) for two years for defects in material and/or workmanship in case of purchase of completely Year .
