2 0 2 3 S C O T T
G E N I U S / G E N I U S ST
M A N U A L
2022 GENIUS / GENIUS ST | ENGLISH 1 |

Advertisement

loading
Need help?

Need help?

Do you have a question about the GENIUS 2023 and is the answer not in the manual?

Questions and answers

Summary of Contents for Scott GENIUS 2023

  • Page 1 2 0 2 3 S C O T T G E N I U S / G E N I U S ST M A N U A L 2022 GENIUS / GENIUS ST | ENGLISH 1 |...
  • Page 2 CONTENT THE GENIUS/GENIUS ST SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND RIDEABILITY. Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm. GEOMETRY & TECHNICAL DATA HEADSET ADJUSTMENT SETTING SAG TWINLOC &...
  • Page 3 GENIUS / GENIUS ST GEOMETRY & TECHNICAL DATA SEATPOST MAX ROTOR 31.6 180 Rr 203 Ft SEATPOST CLAMP MAX CHAINRING 34.9 Tooth 34 TRAVEL MAX TYRE WIDTH 150 Rr 160 Ft SHOCK LENGTH MAIN PIVOT / CHAINSTAY 61802-2RS x 2 SHOCK STROKE LINKAGE / SEATTUBE 61806-2RS x 2...
  • Page 4 GENIUS / GENIUS ST GENIUS / GENIUS ST GEOMETRY & TECHNICAL DATA CONT. Please observe the maximum seatpost insertion so not to damage the frame. Small: 173 mm Max Insertion Medium: 204 mm Max Insertion Large: 234 mm Max Insertion X-Large: 265 mm Max Insertion Please note that on the small sized frame it is only possible to use a 500 ml water bottle,...
  • Page 5 GENIUS / GENIUS ST GENIUS / GENIUS ST HEADSET ADJUSTMENT It is important to install the headset correctly depending on the set up required. There are two types of headset cups. 0° & 0.6° ( 64° & 65°) These can be indentified from the stamp on the inner surface of the headset cup The headset is available in two options:...
  • Page 6 If the sag value is not to your liking The sag indicator is available as a separate within the sag range indicated, adjust part. Check with your Authorised Scott the shock pressure as indicated above. Dealer for the correct installation.
  • Page 7 GENIUS / GENIUS ST GENIUS / GENIUS ST TWINLOC & TRACLOC GENIUS NAME PART NO. CAM TYPE DROPPER GENIUS 900 TWINLOC TSP3 290009 BLUE CAM GENIUS 910 TWINLOC TSP3 290009 BLUE CAM GENIUS 920 TWINLOC TSP3 290009 BLUE CAM GENIUS 930 TWINLOC TSP3 290009 BLUE CAM...
  • Page 8 GENIUS / GENIUS ST GENIUS / GENIUS ST CABLE ROUTING For the alloy frames there will be a protective rubber sleeve inside the headtube for the cables. Rear Brake 297134 SCO CABLE GUIDE H-TUBE INNER SCALE AL 23 Foam tubing: 277026 SCO CABLE ANTI-RATTLE LINER 90CM 20 Dropper Seatpost 2022 GENIUS / GENIUS ST | ENGLISH 8 |...
  • Page 9 GENIUS / GENIUS ST GENIUS / GENIUS ST CABLE ROUTING Twinloc / Tracloc Rear Derailleur 2022 GENIUS / GENIUS ST | ENGLISH 9 |...
  • Page 10 GENIUS / GENIUS ST GENIUS / GENIUS ST SPARE PARTS 297086 SCO STEM ACCESSORY COVER COMBO 22 297672 SCO CABLEGUIDE & BB COVER GENIUS 23 296606 SCO CHAINGUIDE GENIUS 23 296609 SCO AXLE RWS REAR 148X12 GENIUS PLUG 23 10 Nm 296610 SCO SWINGARM REP KIT GENIUS 23 297673 SCO MAIN PIVOT SPARK 22 / LUMEN 23 2022 GENIUS / GENIUS ST | ENGLISH 10 |...
  • Page 11 GENIUS / GENIUS ST GENIUS / GENIUS ST SPARE PARTS CONT. 297522 SCO STEM SPACER/TOP CAP GENIUS 23 Spacers included: 2 x 5 mm / 2 x 10 mm / 2 x 2 mm (Compression Ring & Stem Cap Assembly) The kit fits all stem options, Hixon IC / Combo / AM 1.5 / AM 2 419615 SCO GENIUS CARBON 23 CS / ST PROT...
  • Page 12 SCOTT, the duration of the manufacturer’s guarantee is limited to two years. If a defect on the SCOTT bicycle is remedied within the scope of a manufacturer’s guarantee or a warranty claim, the duration of the manufacturer’s guarantee is not extended. The manufacturer’s guarantee ends, when the first-time buyer transfers ownership of the SCOTT bicycle to a third person.
  • Page 13 English version will be relevant in case of conflict. P.E.D Zone C1, Rue Du Kiell 60 | 6790 Aubange | BelgiumDistribution: SSG (Europe) Distribution Center SA SCOTT Sports SA | 11 Route du Crochet | 1762 Givisiez | 2022 SCOTT Sports SA www.scott-sports.com Email: webmaster.marketing@scott-sports.com...
