- Page 1 OmniAccess 4324 Wireless LAN Switch Installation Guide...
- Page 2 Specifications in this manual are subject to change without notice. Originated in the USA. Trademarks AOS-W and Alcatel OmniAccess 4324 are trademarks of Alcatel in the United States and certain other countries. Any other trademarks appearing in this manual are owned by their respective companies.
-
Page 3: Electromagnetic Interference
Electromagnetic Interference FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Laser Notice
OmniAccess 4324: Installation Guide Warning—This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. EU - Class A This product complies with EN55022 Class A and EN55024 standards. Safety Lithium Battery Notice This product contains a lithium battery which is replaceable only by a trained... -
Page 5: Table Of Contents
Contents Preface Overview of this Manual Related Documents Text Conventions Contacting Alcatel To the Network Manager The Alcatel Wireless LAN Solution xi Deployment Summary System Overview ..Chapter 1 Features Physical Description Installing the Chassis . - Page 6 OmniAccess 4324 Installation Guide: Installation Guide FE Network Ports Serial & Power Over Ethernet Physical Description & LEDs Pin Outs Cables GE Uplink Ports Physical Description and LEDs 22 Serial Console Port Port & Adapter Pin Outs Communications Settings Specifications ... . Appendix C Notes Part 031640-00...
-
Page 7: Preface
Preface This preface includes the following information: An overview of the sections in this manual A list of related documentation for further reading A key to the various text conventions used throughout this manual Alcatel support and service information Overview of this Manual This manual is for trained technicians responsible for installing the OmniAccess 4324 Wireless LAN Switch. -
Page 8: Related Documents
OmniAccess 4324: Installation Guide Related Documents The following items are part of the complete documentation for the Alcatel system: Alcatel Wireless LAN Switch Installation Guide (this manual) Alcatel AOS-W User’s Guide Alcatel AP Installation Guide Text Conventions The following conventions are used throughout this manual to emphasize important concepts: ABLE Type Style... -
Page 9: Contacting Alcatel
Contacting Alcatel Web Site Main Site http://www.alcatel.com Support http://www.alcatel.com/enterprise Telephone Numbers Main US/Canada Main Outside US (800) 995-2612 (818) 880-3500 Preface... - Page 10 OmniAccess 4324: Installation Guide Part 031640-00 May 2005...
-
Page 11: To The Network Manager
To the Network Manager As with any full-featured network equipment, deploying the Alcatel Wireless LAN (Wireless LAN) solution requires a degree of planning. The process may involve multiple components as well as various individuals in your organization. As the network manager, you should become familiar with the components and deployment summary outlined in this section. -
Page 12: Deployment Summary
OmniAccess 4324: Installation Guide Deployment Summary This section outlines the various tasks involved in deploying the Alcatel Wireless LAN solution, and indicates the document where you can find appropriate instructions. —Documents named below are included on the Alcatel Documentation Library CD-ROM. Physical installation of the Alcatel Wireless LAN Switch Installation requires a trained technician who is experienced with handling and installing similar equipment. -
Page 13: Monitoring And Maintenance
Determine how many access points are needed and where they should be located. Simulate network failures and recovery characteristics, and adjust place- ment if necessary. Refer to the Alcatel AOS-W User Guide for instructions. Physical installation of the Alcatel Wireless Access Points This requires a trained technician. - Page 14 OmniAccess 4324: Installation Guide Part 031640-00 May 2005...
-
Page 15: Chapter 1 System Overview
HAPTER System Overview The OmniAccess 4324 Wireless LAN Switch is an enterprise-class switch which connects, controls, and intelligently integrates wireless Access Points (APs) and Air Monitors (AMs) into the wired LAN. This chapter introduces you to the Alcatel Wireless LAN Switch. It describes the general features of the system and illustrates key physical elements. -
Page 16: Physical Description
OmniAccess 4324: Installation Guide The switch firmware can be easily upgraded as future software releases are made available. You can install upgrades using TFTP . Physical Description Front View Rear View 1-1 OmniAccess 4324 Wireless LAN Switch Sys- IGURE System Indicator LEDs 1-1 System LEDs ABLE State... - Page 17 2 GE uplink ports The GE ports can provide high-bandwidth uplinks between the Alcatel Wireless LAN Switch and the wired LAN. The GE port sockets accept a variety of Gigabit Interface Converters (GBICs) for versatility in selecting optical and electrical interfaces. See specifications.
- Page 18 OmniAccess 4324: Installation Guide Part 031640-00 May 2005...
-
Page 19: Chapter 2 Installing The Chassis
HAPTER Installing the Chassis —Installation should be performed by a trained technician. AUTION This chapter covers the following installation topics: Precautions to be observed during installation Requirements for Alcatel Wireless LAN Switch components and rack mounting gear Selecting a proper environment for the Alcatel Wireless LAN Switch Mounting the Alcatel Wireless LAN Switch in a rack Connecting power to the Alcatel Wireless LAN Switch... -
Page 20: Precautions
OmniAccess 4324: Installation Guide Precautions —Hazardous energy is always present while the OmniAccess AUTION 4324 Wireless LAN Switch is plugged into an electrical outlet. Remove all rings, jewelry, and other potentially conductive material before working with this product. Never insert foreign objects into the chassis or any other component, even when the Alcatel Wireless LAN Switch is unpowered or unplugged. -
Page 21: Requirements
Requirements Rack Mounting Kit Using the included rack mounting kit, you can mount the Alcatel Wireless LAN Switch in a standard 19-inch network equipment rack. The rack mounting kit contains the following parts: Left Bracket 2-1 Rack Mounting Kit IGURE —The four 12-24 screws are intended for securing the switch to the rack. -
Page 22: Selecting A Location
OmniAccess 4324: Installation Guide Selecting a Location The Alcatel Wireless LAN Switch, like other network and computing devices, requires an “electronics friendly” environment. Reliable power Verify that your electrical outlet is compatible with the Alcatel Wireless LAN Switch. The switch power input is auto-ranging and accepts 90~132/180~264 VAC, 50 to 60 Hz, 4.0/2.0 A. -
Page 23: Mounting The Chassis
Mounting the Chassis Verify that your rack environment meets requirements (see “Selecting a Location” Attach the rack mounting brackets to the switch chassis as shown in Figure 2-2. 6-32 flat head screws 2-2 Attaching the Rack Mounting Brackets IGURE Orient both brackets so that the narrow flange faces the front. When placed properly, the brackets’... - Page 24 OmniAccess 4324: Installation Guide Attach the Alcatel Wireless LAN Switch to the rack. —To avoid personal injury or damage to equipment, get help AUTION for lifting and positioning the Alcatel Wireless LAN Switch. Also, do not install the Alcatel Wireless LAN Switch in any fashion where instability or uneven mechanical loading may occur.
- Page 25 —Some cabinets require different screws which are not included. Verify that you use the correct screws or fasteners for your rack system. Adhere to clearance requirements. Keep Open to Access Keep Clear for Air Exhaust 2-4 “Keep Clear” Zones IGURE For proper air circulation, leave at least 10 cm (4 inches) clearance for the vents on the left and right of the chassis.
-
Page 26: Connecting Power
OmniAccess 4324: Installation Guide Connecting Power —This procedure should be performed by a trained technician. AUTION Verify you understand the procedure and all precautions. Before beginning, read the entire procedure. Verify you understand all the precautions in these steps as well as those on Verify that your site’s electrical system is compatible with the switch. -
Page 27: Chapter 3 Verifying The Installation
HAPTER Verifying the Installation Once the Alcatel Wireless LAN Switch is physically installed, run the following power-on test: Check for the proper power indicators. Immediately upon power up, you should observe the following: The system Power LED lights solid green The system Status LED is initially off while booting Check the fans to verify they are working. - Page 28 OmniAccess 4324: Installation Guide Once the system has passed the initial power-up test: Connect appropriate network cables (see and cable information). You are now ready to perform the initial setup as described in the Alcatel Quick Start Guide (which is included in the Accessory Kit). Part 031640-00 Appendix B page 13...
-
Page 29: Appendix A Power Management
PPENDIX Power Management Use this worksheet to determine the power required by your Alcatel Wireless LAN Switch. Use a separate copy for each system deployed in your network. System and Location Name of Alcatel Wireless LAN Switch POE Power Requirements Determine the power output required by switch ports that supply Power Over Ethernet (POE). - Page 30 OmniAccess 4324: Installation Guide Part 031640-00 May 2005...
-
Page 31: Appendix B Ports
PPENDIX Ports The OmniAccess 4324 Wireless LAN Switch has a number of ports, each with their own purpose: 24 Fast Ethernet (FE) ports Used for connecting to Access Points (APs) and wired LAN segments. These 10/100 Mbps FE ports aggregate and route traffic under the direction of the switch’s internal software. -
Page 32: Fe Network Ports
OmniAccess 4324: Installation Guide FE Network Ports The Alcatel Wireless LAN Switch has 24 10/100 Mbps Fast Ethernet (FE) network ports. The FE ports are used for connecting the switch to wireless Access Points (APs) and wired LAN segments. These ports can also provide power and serial connectivity to compatible devices. - Page 33 FE Network Ports Ports are grouped in banks of 8 (as shown in are 3 banks, for a total of 24 ports. These ports provide 10/100 Mbps Fast Ethernet connectivity, and in some cases, power and serial connectivity as well. See material starting on LNK/ACT LED Each FE port has its own LNK/ACT LED, located at the left side of the port.
-
Page 34: Pin Outs
OmniAccess 4324: Installation Guide Access Point Status LEDs Each LED represents the status of APs connected to a specific port on the switch. During operation, the LEDs provide the following information: B-3 AP Status LED ABLE Status Description Red (solid) An AP on this port has failed (highest precedence). -
Page 35: Cables
Cables The type of cable required for each port depends on the device being connected: Direct connection to a SPOE compatible device. This requires an 8-conductor Category 5 UTP Ethernet cable with an RJ-45 male connector. A straight-through cable is required to preserve POE voltage polarity. -
Page 36: Ge Uplink Ports
OmniAccess 4324: Installation Guide For cables that run through plenums or air-handling spaces as described in NEC (2002) Article 300.22(C), the cable should be suitable under NEC Article 800.50 and marked accordingly for use in plenums and air-handling spaces with regard to smoke propagation, such as CL2-P , CL3-P , MPP or CMP . Be sure to install cables in accordance with all applicable local regulations and practices. - Page 37 Approved GBICs Approved GBICs are typically selected when the line card is purchased. Although the modules are user-replaceable, for continued safety and reliability only approved modules from approved vendors should be used. The following Class 1 GBICs have been tested with this product: 3-1 Approved GBICs ABLE GBIC Type...
- Page 38 OmniAccess 4324: Installation Guide Cables The following table lists the cable characteristics for approved GBICs: 3-2 GE Cable Characteristics ABLE GBIC Type 1000BASE-T (copper) 1000BASE-SX (optical) Shortwave 850 nm 1000BASE-LX —Be sure to follow the instructions and notifications in “Laser AUTION Notice”...
-
Page 39: Serial Console Port
Serial Console Port The serial console port is located on the front panel of the Alcatel Wireless LAN Switch. This port is for connecting a local management console and can be used to access the text-based Command-Line Interface (CLI) to configure, manage, and troubleshoot the Alcatel Wireless LAN Switch. -
Page 40: Communications Settings
OmniAccess 4324: Installation Guide Communications Settings B-6 Console Terminal Settings ABLE Baud Rate Data Bits Parity Stop Bits Flow Control 9600 None None Part 031640-00 May 2005... -
Page 41: Appendix C Specifications
PPENDIX Specifications Physical C-1 Physical Specifications ABLE Item Specification Size Height 4.45 cm (1.75 inches) Width 44.2 cm (17.4 inches) Depth 40.9 cm(16.1 inches) Weight 5.7 KG (12 lbs.) Environment C-2 Environmental Specifications ABLE Item Specification Temperature Operating: 0 to 40 ºC (32 to 104 ºF) Storage: 0 to 50 ºC (32 to 122 ºF) Humidity 5% to 95% (non-condensing) - Page 42 OmniAccess 4324: Installation Guide Certifications C-4 Certifications ABLE Item Electromagnetic Compatibility Safety Part 031640-00 Specification FCC Part 15 Class A CE ICES-003 Class A VCCI Class A (Japan) The CE approval mark on back of the product indicates that it meets European Directive 89/336/EEC EN 55022 Class A (CISPR 22 Class A), EN55024, EN 61000-3-2, EN 61000-3-3...
-
Page 43: Notes
Notes Notes... - Page 44 OmniAccess 4324: Installation Guide Part 031640-00 May 2005...
