ROSE DISPLAYS ANOGOTCHA SQUARE WITH WALL HANGERS Manual

AnoGotcha™

Parts

End Caps
AnoGotcha Shell
06-5525

Instructions for Hanging

Step 1

Insert T-Top Gotcha Holder into
AnoGotcha Shell. Fig. 1

Step 2

Push end caps into place. Fig. 2

Step 3

Snap the AnoGotcha Holder completely
open so that hinge is turned up as far as
possible. Insert poster into holder until top of
poster meets top of holder. To close snap the
AnoGotcha Holder shut. Fig. 3
With large or curling graphics, it may be easier to
insert graphic at one end and slide into holder
from one end to another.

Step 4

Install Wall Mounting Hangers using
wood screws and a Phillips head screwdriver.
Make sure that the Wall Mounting Hangers
are level. Fig. 4

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoGotcha Holder,
End Caps and MultiClips for future projects.
™
AnoQuick™ and AnoGotcha
trademark of Rose Displays, Ltd. Neither the manufacturer nor any sales
agent may be held liable for injury, loss or damage resulting from the use
of these products. Part #02INSAnoGotchaSQWallHangers
Incept-9.9.02
12AG400
®
are trademarks and Gotcha is a registered
Instruction Sheet
Mounting Hanger
T-Top Gotcha
Figure 1
Wood Screws
Frame Wall or Molly Anchors
06-6067
Figure 2
Figure 3
Figure 4
