  • Page 1 GORA 22 GORA 26 GORA 29 PELLET BOILER Installation, use and maintenance pag. 2...

  • Page 2: Table Of Contents

    SERIAL NO.: Data plates Declaration of Conformity Rating plate reference Moreover, the company hereby declares that: the GORA 22 - GORA 26 - GORA 29 wood pellet stove satisfy the requirements of the following European directives: 2014/35/UE - Low Voltage Directive...
  • Page 3 Proper commissioning is required for activation of the Edilkamin warranty. The warranty is only valid in the country of sale of the product. If the appliance is not commissioned by an authorised technician, Edilkamin will not provide warranty service.

  • Page 4: Safety Information

    DO NOT PLACE DRYING RACKS AT A refer to the warranty certificate inside the DISTANCE WHICH IS LESS THAN THE product: specifically, neither Edilkamin nor SAFETY DISTANCES. Keep flammable the reseller are liable for damage resulting fluids away from the product. Risk of fire.

  • Page 5: Technical Data

    TECHNICAL DATA TECHNICAL CHARACTERISTICS in accord. with EN 303-5 GORA GORA 22 GORA 26 GORA 29 22-26-29 Nominal Nominal Nominal Reduced power power power power Heat input 21,5 25,8 29,2 Available power 20,1 Efficiency 93,5 92,9 92,5 94,3 CO emissions at 10% O...

  • Page 6: Dimensions

    DIMENSIONS GORA 22 - GORA 26 - GORA 29 (dimensions cm) 27,5 27,5 17,1 Combustion air Ø 5 cm Hydraulic connections depend on the optional kits R-FX, R2-FX o RW-FX. You can find further information in the Smoke outlet paragraph “water circuit installation”...
  • Page 7 ACCORDING TO COMMISSION REGULATION (EU) 2015/1187 The present document cancels and supersedes document issued November 29, 2018. EDILKAMIN – GORA 22 Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a...
  • Page 8 N.A. emission abatement equipment, if applicable 0,004 In standby mode Contact details Name and address of the manufacturer or its authorized representative. Tel. +39 02 937621 Manufacturer: EDILKAMIN SPA www.edilkamin.it Via Mascagni 7 mail@edilkamin.it 20020 Lainate (MI) – ITALY...
  • Page 9 ACCORDING TO COMMISSION REGULATION (EU) 2015/1187 The present document cancels and supersedes document issued November 29, 2018. EDILKAMIN – GORA 26 Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a...
  • Page 10 N.A. equipment, if applicable In standby mode 0,004 Contact details Name and address of the manufacturer or its authorized representative. Tel. +39 02 937621 Manufacturer: EDILKAMIN SPA www.edilkamin.it Via Mascagni 7 mail@edilkamin.it 20020 Lainate (MI) – ITALY...
  • Page 11 ACCORDING TO COMMISSION REGULATION (EU) 2015/1187 The present document cancels and supersedes document issued November 29, 2018. EDILKAMIN – GORA 29 Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a...
  • Page 12 N.A. equipment, if applicable 0,004 In standby mode Contact details Name and address of the manufacturer or its authorized representative. Tel. +39 02 937621 Manufacturer: EDILKAMIN SPA www.edilkamin.it Via Mascagni 7 mail@edilkamin.it 20020 Lainate (MI) – ITALY...

  • Page 13: Water Circuit Installation

    WATER CIRCUIT INSTALLATION PLUMBING We offer four internal kits (optional) The products are equipped with closed expansion KIT R-FX tanks. for installation without instant DHW production. If the expansion tank is built into the product, this KIT R2-FX does NOT ensure proper protection against thermal For installation without instant DHW production with expansion caused by water in the entire system.
  • Page 14 WATER CIRCUIT INSTALLATION To assemble the kits, move the probe (S) from point A to point B PIPE KIT Measurements in mm left side left side 144 mm 144 mm R-FX - RW-FX R2-FX floor floor...
  • Page 15 WATER CIRCUIT INSTALLATION OPTIONAL HYDRAULIC KITS All kits are supplied with instructions for their connection to the boiler stove. The technicians have a dedicated paper template for each product. Make sure to use the correct template for the model being installed. Position the template flush with the floor and aligned with the left hand side of the outer edge boiler stove.

  • Page 16: Installation

    INSTALLATION ADAPTATION FOR PELLET LOADING SCREW Fig. 1 SYSTEM (optional) The boiler is designed for pellet loading by means of a screw feeding system. ATTENTION: the boiler must be positioned at least 30 cm from the wall behind it To install the system, proceed as follows: N.B.: before starting, turn the boiler off and di- sconnect the electricity supply wire.
  • Page 17 INSTALLATION REMARKS ON INSTALLATION REMARKS ON INSTALLATION Note that: Note that: • • installation must be carried out by authorised installation must be carried out by authorised technical personnel. technical personnel. • • all local and national laws and European standards all local and national laws and European standards must be met in the installation and use of the must be met in the installation and use of the...
  • Page 18 INSTALLATION THE FLUE THE FLUE: EXTERNAL AIR INTAKE Further to the general prescriptions for the fumes duct In general, we suggest two ways to ensure a proper and flue, the flue: : flow of combustion air. • must serve solely to exhaust fumes •...
  • Page 19 • preferably have a circular internal cross section, or Contact the authorised Edilkamin Technical Assistance with a ratio of the sides of less than 1.5 Centre. • terminate at roof level with a proper chimney pot:...
  • Page 20 TERMINAL BOARD TERMINAL BOARD There is a bracket with a terminal board and 5 cableways* on the back (remove the protective cover fixed by two screws). Examples of possible connection configurations are given below. * The cableways are provided in the pack above the product structure.

  • Page 21: Instructions For Use

    DESCRIPTION OF THE DISPLAY INTERFACE The sole interface is the display. The views display the functions and are described in the following sections ON/OFF BUTTONS The display has 5 buttons ON/OFF to switch from the OFF mode to the ON mode. In the menus, it can be used to confirm and return to the main screen.
  • Page 22 DESCRIPTION OF THE DISPLAY THE READING AREA OF THE DISPLAY is divided in two parts: • the status bar, above the horizontal line; • main area, under the horizontal line. The views display the functions and are described in the following sections The status bar contains: The main area contains: •...
  • Page 23 OPERATIONAL LOGIC the product operates with the POSSIBLE MODES (described below): • OFF MODE • ON MODE • STAND BY MODE • ALARM MODE OFF MODE The product is “disabled” and does not produce heat. The product may turn on only for the anti-freeze function (described on this page).
  • Page 24 OPERATIONAL LOGIC From the OFF screen, press and hold the ON/OFF button to go to the ON screen. ON MODE The product is “active” and can produce heat. The product can be on/in ignition. The display shows • the current time •...
  • Page 25 OPERATIONAL LOGIC ON MODE with STAND BY While in stand-by mode, and ON, the In ON mode with STAND BY (the product is “active” product turns on only if there is a heat but with stand by function enabled) the product turns request.
  • Page 26 COMMANDS AND MENU From the display, you can: Switching on and off will take a few minutes, • Switch from OFF to ON modes, by during which the flame must appear or go pressing and holding the ON/OFF button off. Just wait without taking any action. During ignition, the display shows the text •...
  • Page 27 STAND BY MENU Menu Press the “M” button to display the menu. When the menu displays, the buttons have the following functions: “+” : scroll up “-” : scroll down press and release “OK”: enter menu option press and release “M”: quit menu option Press the ON/OFF button to confirm and return to the main screen.
  • Page 28 CRONO MENU Crono - PROGRAM(figures on the side) When the Crono function is active, the user sets a temperature setpoint and a time zone for which that setpoint is specified. PROGRAM The setting takes different steps, which can also be not consecutive: •...
  • Page 29 CRONO MENU Setting of the time periods, “SET” on the display (figure on the side) From Crono, press the “OK” button to enter the “SET” function. The first screen allows you to choose whether to apply the time periods for 7/7 days, 5/7, weekend only or day by day.
  • Page 30 CRONO MENU Display the Crono function, “SHOW” (figures on the side) From Crono, press the “OK” button to enter the “DISPLAY” function. The buttons have the following functions: SHOW “+”: to scroll through the days ahead “-” : to scroll through the days back “OK”: return to the previous menu “M”: return to the previous menu ON/OFF: return to the main screen.
  • Page 31 TEMPERATURE MENU Setting water Temperature (“TEMPERATURE” on the display) Allows you to set the boiler temperature and the accumulator temperature. If the external probe is active, it allows you to set the climatic curve instead of the boiler temperature. To access the function from the main menu (as indicated in the Menu section above), press the M button.
  • Page 32 VARIOUS MENUS Load Pellets - SCREW LOAD Allows you to load pellets after the worm screw has emptied following a no-pellets alarm. Used by the technician during commissioning. Available only in the OFF state. If you attempt to activate the function in other states, access is not granted. To access the function from the main menu (as indicated in the Menu section above), press the M button.
  • Page 33 VARIOUS MENUS Beep Allows you to enable/disable the beep. To access the function from the main menu (as indicated in the Menu section above), press the M button. Scroll using the +/- buttons and select the function by pressing OK. Use the “+/-”...

  • Page 34: Maintenance

    MAINTENANCE Before performing any maintenance, disconnect the appliance from the mains. • Regular maintenance is required for the boiler to function correctly. Any problems resulting from lack of maintenance will immediately void the warranty. When cleaning is necessary, the message “Clean - exchanger” will appear on the panel if further cleaning is necessary.
  • Page 35 MAINTENANCE DAILY MAINTENANCE (2-3 days) Operations must be performed when the boiler is off, cold and unplugged from the power supply. Cleaning should be carried out with the aid of a vacuum cleaner, the whole procedure takes up a few minutes. •...
  • Page 36 MAINTENANCE • Vacuum around the electrical element (4 - fig. C). ACTIVATE THE BRUSHES TO CLEAN THE EXCHANGERS (*), ALSO WHEN THE STOVE IS LIT, USING THE GLOVE; • - Shake the cleaning handle positioned under the pellet loading cover (5 - fig. D). fig.
  • Page 37 You should clean the chimney system at least once a Using non-original spare parts may damage the year (check local regulations for details). appliance and relieves Edilkamin of all liability for damage that may arise from doing this. If you fail to regularly clean and inspect the system, Do not make unauthorised modifications.

  • Page 38: Troubleshooting

    TROUBLESHOOTING If problems occur, the product shuts itself off automatically. The display will show the reason (see below). Do not disconnect from the power supply. To start the product up again, allow the shut-down procedure to complete, then press the ON/OFF button.
  • Page 39 TROUBLESHOOTING MESSAGE PROBLEM SOLUTION • Check the type of pellet (contact the technician if in Shut-down due to exceeding doubt) maximum smoke temperature • contact the technician Switching OFF due to excessive • see HO7 overheating of the product Shut down due to gear motor •...
  • Page 40 If the water in the boiler stove reaches a temperature of 85°C, the boiling stove shuts down without switching to alarm mode. The text STBY appears on the display next to the room temperature. The product is working, but it must be serviced by an authorised Edilkamin technician. MAINTENANCE (SIGNAL THAT DOES NOT CAUSE SHUT-DOWN) A wrench symbol is shown on the display after 2000 hours of operation.
  • Page 41 TROUBLESHOOTING SAFETY THERMOSTAT If pellet loading fails, especially after a power failure, check whether the safety thermostat has intervened (A). If the thermostat has been tripped it must be reset using the reset button behind the boiler after having removed the protective cap (A).
