APPENDIX

REFERENCE TABLES AND GRAPHS

APPLIANCE
Single PL Light
B & W TV
Computer
Color TV
Blender
Skil Saw
Toaster
Microwave
Hot Plate
If the current draw at 120 VAC is known, then the battery amperage at 12VDC will be 10 times the AC
amperage divided by the efficiency (90% in this table).
Motors are normally marked with their running rather than their starting current. Starting current can be
five times running current. Keep this in mind when sizing a motor into a system.
Refrigerators and icemakers typically run about 1/3 of the time. Therefore, their average battery current
draw is 1/3 what their amp rating would indicate.
AWG
14
12
10
8
6
4
2
1
0 (1/0)
00 (2/0)
000 (3/0)
0000 (4/0)
Note: Stranded wire sizes and ampacity for 75°C.
Copyright  Trace Engineering Company, Inc.
Page
5916 - 195th Street N. E.
130
Arlington, WA 98223

Table 9, Power Consumption Of Common Appliances

WATTS 5
10 .1
50 .4
100 1
200 2
400 3
800 6
1000 8
1200 10
1800 15

Table 10, AWG to Metric Wire Conversion Chart

DIAMETER/MM
1.63
2.05
2.59
3.26
4.11
5.19
6.54
7.35
8.25
9.27
10.40
11.68
TIME IN MINUTES
15 30 60
.3 .7 1.3
1 2 4
2 4 8
4 8 17
8 17 34
17 34 67
23 46 93
28 57 114
44 88 176
AMP-HOURS
AREA/MM²
2.08
3.31
5.27
8.35
13.3
21.2
33.6
42.4
53.4
67.5
85.0
107.2
