Summary of Contents for Classe Audio CAP-2100 - MANUEL 2
Page 1
Owner’s Manual CAP-2100 Integrated Amplifier Manuel du propriétaire CAP-2100 Amplificateur intégré...
Page 2
WARNING:TO REDUCETHE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
Page 3
Important Safety Instructions Caution: Please read and observe all warnings and instructions in this owner’s manual and all those marked on the unit. Retain this owner’s manual for future reference. 1. Do not attempt to service this product yourself. Do not open the cover for any reason. There are no user-serviceable parts inside.
Contents Welcome to the Classé family................5 a word about installation................5 Unpacking and Placement................6 unpacking your integrated amplifier ............6 placement ....................6 ventilation ....................6 custom installations.................. 6 serial number ................... 6 register your purchase! ................7 operating voltage..................7 warm up/break-in period................
Welcome to the Classé family Congratulations on your purchase of a Classé product. It is the result of many years of continuous refinement, and we are sure that you will enjoy it for many years to come. We value our relationship with our customers. Please allow us to stay in touch with you by returning your warranty card now, before you pack up the shipping carton of your new product and forget all about it.
Unpacking and Placement unpacking your Carefully unpack your integrated amplifier according to the supplied integrated amplifier instructions, and remove all accessories from the carton. Important! Keep all packing materials for future transport of your Classé product. Shipping your new component in anything other than its purpose-designed packing material may result in damage that is not covered by the warranty.
register your purchase! Having found the serial number, now would be a good time to fill out the registration card. Please register your purchase so we can advise you of updates and other items of interest. It will take only a minute or so. Please complete the card now, before you forget. operating voltage The CAP-2100 integrated amplifier is set at the factory for 100V, 120V, 230V, or 240V AC mains operation, as appropriate for the country in which it is to be sold (230V only in European Union countries, in compliance with CE regulations.)
warm up/break-in period Your new Classé integrated amplifier will deliver outstanding performance immediately. However, you should expect to hear it improve somewhat as it reaches its normal operating temperatures and its various components “break-in.” It has been our experience that the greatest changes occur within the first 300 hours, as the integrated amplifier reaches thermal equilibrium and the capacitors fully form.
Special Design Features flexible graphical The LCD touchscreen on the front panel of your new component supports an user interface extremely flexible and versatile graphical user interface (GUI) while maintaining a clean, uncluttered appearance. The CAP-2100 provides a range of controls that might otherwise require dozens of buttons and knobs on the front panel.
extensive listening tests Excellent measured performance is to be expected in world-class products, and Classé products deliver that performance. However, experience has shown that technical excellence alone is insufficient to guarantee subjectively musical results. For this reason, all Classé products are laboriously fine-tuned during the development process by carefully controlled listening tests.
������� ���� ���� �������� Front Panel Standby button & LED indicator The front panel Standby button will toggle the integrated amplifier between operate, its fully operational state, and a standby mode that leaves the integrated amplifier off, yet ready to respond to system commands via any of the supported control options (e.g.
Page 12
Menu button Pressing the front panel Menu button will call up the main menu system, replacing the normal operational menu and status display in the LCD touchscreen. LCD touchscreen Much of your interaction with the CAP-2100 will be with the LCD touchscreen (and the CAP-2100’s supplied remote control).
Page 13
In addition to receiving IR commands, the CAP-2100 can also transmit IR commands so they may be learned by third-party learning remote controls. The CAP-2100 includes a comprehensive list of discrete IR commands to facilitate the creation of reliable macros. Specifically, there are discrete codes for all commands that normally operate as “toggle”...
Single-ended (RCA) main outputs Single-ended cables using RCA connectors are the most common form of analog connection used in consumer electronics. When implemented carefully and used with high quality interconnect cables, this standard can provide excellent performance. Classé has gone to extraordinary effort to ensure that the single-ended (RCA) outputs of your integrated amplifier are as good as possible.
Page 16
Balanced (XLR) input These XLR jacks accept right-channel and left-channel balanced signals from a source component with balanced outputs. This input may be selected by touching the corresponding button on the main operational screen of the front panel touchscreen. The pin assignments of the XLR input connectors are: Pin 1: Signal ground Pin 2: Signal + (non-inverting) Pin 3: Signal –...
Page 17
The integrated amplifier is designed to respond to IR commands of 5 VDC, with the tip of the mini-plug defined to be positive relative to the shank of the plug. Classé CAN Bus Control Ports These RJ-45 connectors are reserved for future control and communication applications using Classé...
Page 18
Ground terminal The ground terminal on your integrated amplifier is most often used for the ground wire of a turntable, assuming you have the optional phono module installed (see your authorized Classé dealer for more information on this option if you are interested). Connecting the ground wire from your turntable’s tonearm to this screw terminal usually minimizes any hum or buzzing to which the turntable might otherwise be susceptible.
The Remote Control Your new integrated amplifier comes with a versatile remote control which can control both the CAP-2100 itself and several aspects of the rest of a Classé-based system. The buttons are arranged in logical groups according to their functions. �������...
Page 20
Input Selection These Up and Down arrow keys will cycle through the active inputs on your CAP-2100. If you have inputs you are not using, we suggest deactivating them in order to provide faster, easier access to the inputs you are actually using. (See the section The Menu System, the next section in this manual, for information on how to do this.) System Controls...
The Menu System Your CAP-2100 includes a versatile LCD touchscreen which supports both an attractive information display and a flexible menu system. While its use is quite intuitive, it is also quite extensive. This section of the owner’s manual outlines the many capabilities found in the menu system.
main menu system Pressing the front panel Menu button to the left of the LCD touchscreen brings up a comprehensive main menu system, the top two levels of which are shown above. This menu system provides access to many installation-specific features that let you customize how the CAP-2100 works within the context of your particular system.
rotary The rotary knob on the front panel does not directly control the volume. Instead, it controls circuitry that does so with greater fidelity and precision than traditional volume potentiometers could ever achieve. Since the volume control circuitry is under software control, it is possible to customize its behavior under various conditions.
Page 24
Of course, it is possible to bump into the knob by accident, which might result in its spinning very quickly indeed. Rather than increasing the volume uncontrollably under these conditions, the CAP-2100 actually slows everything down again as a safety measure against accidentally blowing up your speakers. In fact, if you like you may establish a speed limit beyond which the knob will simply be ignored.
• speed limit: establishes a maximum rotary speed, beyond which there will be no change in volume whatsoever; the knob’s input will be ignored completely until it slows down below the speed limit. • reset defaults: if after experimenting with various settings you decide you prefer it the way it operated as it came from the factory, pressing this button will restore the factory default settings.
Page 26
• The button acts like the backspace key on a computer keyboard, moving the cursor to the left and eliminating any characters along the way. • The button moves the cursor to the right, adding characters along the way. (Change each character to what you want as you –...
phono gain The phono gain menu is only active if the optional phono module is installed; otherwise it is grayed out. When it is installed, the CAP-2100 will automatically recognize it, rename the line 1 input to phono, and activate the input on the main menu.
teach IR The CAP-2100 provides discrete infrared (IR) command codes for all its functions, a list that extends far beyond what is required by normal remote controls. However, many of these functions are critical if you plan to create a customized remote control with macros that take command of your entire system.
brightness The brightness setting of the CAP-2100 has three possible values: low, medium, and high. Select the appropriate setting based on the level of ambient light typically found in your listening room while using the system. A high brightness setting usually works best in brightly-lit rooms; you may find that a lower setting is less visually intrusive under more subdued lighting conditions.
remote Fkeys The remote control supplied with the CAP-2100 has four function keys (Fkeys) that allow you to have instant, easy access to specific system functions that might otherwise be buried in a menu somewhere. For example, if you use the balance control frequently, you may want to consider programming one of the Fkeys to take you straight to that screen.
status The primary function of the status screen is to provide information about the current operating status of the CAP-2100. It also provides access to version info screen, which displays information about the unit’s software, and the sensors screen, which displays information from the internal sensors about the temperature and input power.
Troubleshooting In general, you should refer any service problems to your Classé dealer. Before contacting your dealer, check to see if the problem is listed here. If it is, try the suggested solutions. If none of these solves the problem, contact your Classé dealer.
Page 33
Only one speaker seems to be playing. • Check the main balance control setting of the CAP-2100 by pressing the Menu button, followed by the Balance button. • Does the problem occur with all inputs? If so, check the interconnect cables between the source component and the CAP- 2100 input.
Page 34
There is a mechanical hum coming from the unit. • This symptom suggests you have electrical noise on your AC mains line. Try connecting to another AC circuit (not merely a different plug, but a different circuit). • Check to see if you have any halogen lighting or dimmers on the same circuit as the integrated amplifier, as they can be the cause of hum in power supply transformers.
Page 35
e. Finally, if everything is still fine, place the integrated amplifier in standby and carefully reconnect the speaker wires. Check both ends of the speaker wires for possible short circuits. Then power up the integrated amplifier again. If the integrated amplifier remains functional (the fuse does not blow), then the original fuse probably blew in order to protect the integrated amplifier from a large AC mains surge.
Care and Maintenance cleaning the cabinet To remove dust from the cabinet of your integrated amplifier, use a feather duster or a soft, lint-free cloth. To remove dirt and fingerprints, we recommend isopropyl alcohol and a soft cloth. Dampen the cloth with alcohol first and then lightly clean the surface of the integrated amplifier with the cloth.
Specifications Classé Audio reserves the right to make improvements without notice. ■ Power output (both channels driven) 100W/ch continuous rms @ 8Ω 200W/ch continuous rms @ 4Ω ■ Frequency response 10Hz – 22kHz (+0/-0.1dB) 10Hz – 155kHz (+0/-3.0dB) ■ Phase less than -10°...
Page 38
ATTENTION : POUR RÉDUIRE LES RISQUES D’INCENDIE ET D’ÉLECTROCUTION, NE JAMAIS EXPOSER CET APPAREIL À LA PLUIE OU L’HUMIDITÉ. ATTENTION RISQUE D’ÉLECTROCUTION NE PAS OUVRIR ATTENTION : POUR RÉDUIRE LES RISQUES D’ÉLECTROCUTION, NE JAMAIS ÔTER LE CAPOT DE L’APPAREIL. AUCUNE PIÈCE ACCESSIBLE PAR L’UTILISATEUR À...
Page 39
Importantes instructions concernant la sécurité Attention : Veuillez lire et observer toutes les instructions et recommandations de ce manuel d’utilisation, ainsi que celles inscrites sur l’appareil lui-même. Conservez soigneusement ce manuel d’utilisation. 1. Ne tentez pas de réparer vous-même l’appareil. Ne jamais retirer son capot, pour quelque raison que ce soit.
Page 40
Sommaire Bienvenue dans la famille Classé ..............41 un mot concernant l’installation............. 41 Déballage et installation ................42 déballage de votre amplificateur intégré..........42 installation ..................... 42 aération....................42 installations personnalisées ..............42 numéro de série ..................42 enregistrez votre achat ! ................. 43 tension d’alimentation................
Bienvenue dans la famille Classé Nous vous félicitons pour l’achat de cet appareil Classé. Il représente le résultat de nombreuses années d’améliorations continues, et nous sommes certains qu’il vous apportera des années de plaisir. Nous attachons une grande importance à la relation avec nos clients. Nous vous remercions donc de bien vouloir dès maintenant nous retourner votre carte de garantie, avant que vous ne stockiez le carton d’emballage et ne l’oubliez.
Déballage et installation déballage de votre Déballez soigneusement l’amplificateur intégré selon les instructions fournies, amplificateur intégré puis retirez tous les accessoires du carton. Important ! Conservez l’emballage et tous ses éléments internes pour tout transport futur de votre appareil Classé. L’utilisation de tout autre emballage pourrait endommager l’appareil, dommages non couverts par la garantie.
enregistrez votre achat ! Puisque vous venez de trouver et de noter le numéro de série, c’est le moment de remplir la carte de garantie ! Veuillez enregistrer votre achat afin que nous puissions vous avertir des futures éventuelles mises à jour et améliorations le concernant.
période de rodage Votre nouvel amplificateur intégré Classé ne délivrera pas la quintessence de ses performances immédiatement. Vous constaterez une première amélioration quand l’appareil aura atteint sa température normale de fonctionnement, tous ses composants internes étant alors « stabilisés ». Selon notre expérience, les changements les plus importants surviennent après environ 300 heures de fonctionnement, après que l’appareil a atteint son équilibre thermique parfait et que ses condensateurs soient parfaitement efficaces.
Caractéristiques particulières interface graphique L’écran tactile LCD de la face avant de votre nouvel appareil propose une interface utilisateur graphique (GUI) d’apparence superbe et très pratique. Le CAP-2100 propose ainsi un nombre de réglages qui nécessiterait sans cet écran des douzaines de touches et boutons sur la façade. Malgré sa puissance et ses nombreuses possibilités, il reste d’utilisation simple et intuitive au quotidien.
Ce niveau de raffinement ne peut être que le résultat d’une expérience sans cesse affirmée mais améliorée, et non le résultat de ceux qui passent toujours d’une notion à une autre. C’est ce qui explique la constance des performances de tous les maillons Classé (tous basés sur des étages de gain analogues), et aussi la constance des excellentes critiques et récompenses décernées par leurs propriétaires comme par les journalistes spécialisés.
������� ���� ���� �������� Face avant Touche de mise en veille Standby et indicateur LED La touche de mise en veille Standby de la face avant permet de faire basculer l’amplificateur intégré entre son état de fonctionnement normal (dit « operate ») et son état de mise en veille (dit « standby ») qui l’éteint tout en le laissant capable de répondre aux commandes du système via n’importe laquelle des options de commande (entrée infrarouge IR, commutation courant continu Trigger, prise CAN Bus ou prise RS-232).
Page 48
Touche Menu Une pression sur la touche Menu de la face avant appelle le menu principal (Main menu), qui remplace le menu de fonctionnement normal et le statut du fonctionnement en cours dans l’écran tactile LCD. Écran tactile LCD La plupart de vos interventions sur le CAP-2100 se feront par l’intermédiaire de cet écran tactile LCD (et la télécommande du CAP- 2100).
Page 49
En plus de recevoir des signaux IR, le CAP-2100 peut également transmettre des commandes IR après qu’elles ont été apprises depuis des télécommandes universelles. Le CAP-2100 utilise une liste de commandes infrarouge uniques, pour faciliter la création de macrocommandes fiables. En particulier, les commandes infrarouge sont distinctes pour les opérations de commutation (par exemple, il existe des codes infrarouge spécifiques pour l’état de veille, pour l’état de fonctionnement réel, en plus de la commande unique permettant de basculer d’un état à...
Si vous avez besoin de ces sorties niveau préamplificateur, branchez-les sur les entrées asymétriques de votre amplificateur de puissance en utilisant des câbles RCA blindés de la meilleure qualité possible. Contactez votre revendeur agréé Classé pour de plus amples informations sur le choix de ces câbles.
Page 52
Le câblage des broches de l’entrée femelle XLR est le suivant : Broche (pin) 1 : masse du signal Broche 2 : signal + (non inversé) Broche 3 : signal – (inversé) Masse externe de la prise : masse du châssis. Ce brochage correspond à...
Page 53
L’amplificateur intégré est conçu pour répondre à des commandes infrarouge de 5 volts CC (continu), la pointe de chaque mini-jack étant définie comme le positif par rapport au corps de la prise. Prises de commande Classé CAN Bus Ces prises type RJ-45 sont prévues pour de futures applications de commande et de télécommunication, utilisant les spécifications du système de réseau de commande développé...
Page 54
11. Prise de masse (Ground) La prise de masse de votre amplificateur intégré sera le plus souvent utilisée pour brancher le fil de masse présent en sortie de votre platine tourne-disque, si vous avez le module Phono installé (contactez votre revendeur agréé...
La télécommande Votre nouvel amplificateur intégré est livré avec une télécommande pouvant piloter le CAP-2100 lui-même, mais aussi plusieurs autres fonctions d’un système complet Classé. Ses touches sont arrangées en groupes logiques, par rapport aux fonctions télécommandées. Fonctions de base Il s’agit des quatre touches placées en haut de la télécommande, destinées à...
Page 56
Sélection des entrées Ces deux touches/flèches haut et bas vous permettent de passer d’une source active du CAP-2100 à une autre. Si certaines entrées ne sont pas effectivement utilisées, nous vous suggérons de les désactiver de manière à pouvoir naviguer plus rapidement et plus efficacement entre les entrées réellement utilisées.
Le Système des Menus Votre CAP-2100 possède un écran tactile LCD qui permet tout à la fois d’afficher de nombreuses informations, mais aussi d’accéder à un système par menus. Ce système est aussi simple à utiliser que sophistiqué dans le nombre des paramètres qu’il autorise.
menu principal système (main) Une pression sur la touche Menu de la face avant, placée à gauche de l’écran tactile LCD, entraîne l’affichage du menu principal Réglage du système, dont les deux premières pages sont illustrées ci-dessus. Ce menu vous donne accès aux caractéristiques particulières de l’installation, ce qui vous permet de personnaliser le CAP-2100 par rapport au contexte particulier de votre installation.
bouton rotatif Le bouton rotatif de la face avant ne commande pas directement le volume. Il commande en fait un circuit apportant plus de précision et de fidélité qu’un classique potentiomètre de volume ne pourrait jamais le faire. Puisque ce circuit est sous le contrôle d’un logiciel, il est possible de le personnaliser sous certaines conditions.
Page 60
Naturellement, il est possible de modifier accidentellement le réglage du volume par un contact inopiné. C’est pourquoi, dans le cas d’un changement brutal, le CAP-2100 ralentit automatiquement la modification afin d’éviter la surcharge accidentelle des enceintes acoustiques. En pratique, vous pouvez établir une limitation de la vitesse (speed limit) au-delà...
• limite de vitesse (speed limit) : établit une vitesse de rotation maximum du bouton, au-delà de laquelle le volume ne change pas ; tout changement de volume est alors ignoré tant que la rotation n’est pas arrêtée, et que le bouton est ensuite tourné plus lentement.
Page 62
• La touche t réagit comme la touche de retour en arrière du clavier d’un ordinateur, déplaçant le curseur vers la gauche et éliminant éventuellement le caractère qui s’y trouvait. • La touche u déplace le curseur vers la droite, ajoutant un caractère au passage (Vous modifiez les caractères désirés en utilisant les touches + et -.) –...
gain Phono Le menu gain Phono (phono gain) n’est actif que si le module optionnel Phono (phono module) est installé ; dans le cas contraire, il reste grisé. Lorsqu’il est installé, le CAP-2100 le reconnaît automatiquement, renomme l’entrée « line 1 » en « phono », et active cette entrée dans le menu principal. Le réglage du gain Phono est très simple : choisissez faible gain (low gain) pour la plupart des cellules à...
Apprentissage infrarouge (IR) Le CAP-2100 fournit des codes de commandes infrarouge (IR) bien différenciés pour toutes ses commandes, soit une liste bien plus étendue que ce que nécessitent les télécommandes normales. Cependant, la plupart de ces codes deviennent critiques dès que vous désirez créer une télécommande réellement personnalisée, avec notamment plusieurs macrocommandes capables de gérer l’intégralité...
luminosité Le réglage de luminosité (brightness) du CAP-2100 prend trois valeurs possibles : faible (low), moyenne (medium) et élevée (high). Choisissez la valeur désirée en fonction de la lumière ambiante de votre salle d’écoute. Une luminosité élevée est préférable dans une pièce très éclairée, tandis qu’une luminosité...
balance Le contrôle de balance vous donne une double indication, numérique et graphique, du réglage de balance en cours du CAP-2100. Certains enregistrements ne présentent pas une balance correcte entre leurs canaux gauche et droit. Si un enregistrement vous semble (par exemple) déséquilibré vers la gauche, vous pouvez rétablir une perspective correcte en utilisant ce réglage de balance.
note concernant l’utilisation Notez que toutes les télécommandes Classé sont équipées de ces mêmes quatre des touches Fkey touches de fonction Fkeys, qui sont toutes liées entre elles. Ainsi, la fonction programmée pour la touche F1 de la télécommande de l’amplificateur intégré, par exemple, enverra le même code infrarouge que la touche F1 du lecteur de Vous devez donc prendre soin d’assigner la même fonction à...
Problèmes de fonctionnement En règle générale, en cas de problème, contactez immédiatement votre revendeur agréé Classé. Mais, avant de contacter celui-ci, vérifiez que votre problème ne soit pas répertorié ci-dessous. Si aucune des solutions décrites ici ne résout le problème, alors contactez votre revendeur agréé Classé. Tout semble correct, mais aucun son ne sort.
Page 69
• Si aucune de ces solutions ne fonctionne, contactez votre revendeur agréé Classé pour assistance. N’essayez jamais par vous- même d’intervenir à l’intérieur de l’appareil. Il n’y a à l’intérieur aucune pièce susceptible d’être modifiée par l’utilisateur. Seule une enceinte acoustique semble fonctionner. •...
Page 70
Il y a un bruit mécanique en provenance d’un appareil. • Ce symptôme sous-entend que vous avez un problème de parasite directement sur la ligne d’alimentation secteur. Essayez d’utiliser une autre ligne secteur dans votre habitation (pas seulement une autre prise murale ; une autre ligne d’alimentation). •...
Page 71
d. Si tout se passe correctement, placez l’amplificateur dans son mode de veille Standby et rebranchez les câbles d’entrée, puis allumez-le. Si le fusible fond à nouveau (ou que l’amplificateur se met en mode de protection), vous avez un sérieux problème avec une des sources ou le préampli-processeur éventuellement branché...
Entretien entretien du coffret Pour ôter la poussière du coffret de votre amplificateur intégré, utilisez un plumeau ou un chiffon très doux et non pelucheux. Pour retirer la saleté incrustée ou des traces de doigts, nous recommandons de l’alcool isopropyle et un chiffon doux.
Spécifications Toutes ces spécifications sont certifiées conformes et exactes au moment de l’impression. Classé Audio se réserve le droit d’apporter des améliorations sans préavis. ■ Puissance de sortie 100 W/canal continus rms @ 8 Ω (les deux canaux en service) 200 W/canal continus rms @ 4 Ω...
