Summarization of Contents
Product Information
Product Overview and Specifications
Details product models, dimensions, weight, and gain (dBi).
StarterDish UM Package Contents
Lists all items included in the product package.
Single Unit Components Breakdown
Illustrates and lists parts for a single unit assembly.
Installation Procedures
Step 1: Pole Mounting
Attaches the dish assembly to the pole.
Step 2: Subreflector Attachment
Connects the subreflector to the main dish.
Step 3: Secure Mounting Bracket
Secures the mounting bracket to the dish assembly.
Step 4: Attach Bracket Arm
Connects the bracket arm to the assembly.
Step 5: Subreflector Installation
Installs the subreflector with a spring latch mechanism.
Step 6: Final Bracket Attachment
Attaches the main bracket with screws and nuts.
Step 7: Pole Mount Orientation
Shows correct orientation for small and large pole mounts.
Step 8: Polarization Setup
Configures dual slant or H-V polarization.
Step 9: Waveguide Installation
Installs the waveguide onto the assembly.
Step 10: Adapter Assembly
Assembles the adapter using a Phillips screwdriver.
Step 11: Final Dish Attachment
Attaches the dish assembly to the mounting bracket.
Uninstallation Procedures
Step 12: Dish Removal
Details the process for uninstalling the dish.
Pre-Installation Setup
Step 13: Left-side Setup Release
Releases screws for left-side pole installation.
Step 14: Left-side Setup Tighten
Tightens screws for left-side pole installation.
Compatible Devices
Compatible Devices Information
Provides information on compatible devices and company contacts.
