Summarization of Contents
Enclosure Access and Disassembly
Remove Top Cover Screws
Remove the three red-marked screws from the top cover for initial access.
Remove Battery Slot Panel Screw
Optionally remove the screw from the Li Battery slot panel for access.
Remove Back Panel Screws
Remove the four red-marked screws from the back panel for further disassembly.
Motherboard and DRAM Replacement
Remove Motherboard Securing Screws
Remove the two screws securing the motherboard to the chassis.
Disconnect System Cables
Disconnect FAN, SATA DOM/SSD/HDD, and 4-pin power cables from the motherboard.
Slide Out Motherboard and Replace DRAM
Slide the motherboard out and replace the DRAM module in the upper DIMM slot.
Install New DRAM Module Correctly
Insert new DRAM at 45 degrees, aligning with latches, and secure it properly.
Post-Assembly Connection Verification
Check Button and Battery Cable Connections
Verify the micro switch (power button) and battery cable connections.
Verify Internal Cabling
Confirm internal cable connections, including power and data interfaces.
Verify SATA Cable Connections
Ensure SATA cables (SATA1 to SATA4) are correctly connected and seated.
