Ronda 5040.E Technical Instructions

Chronographs, big date & date, different calendar systems, alarm
Hide thumbs Also See for 5040.E:

Advertisement

Quick Links

Download this manual
RONDA startech 5000
Chronographs, Big Date & Date,
different calendar systems, Alarm
Caliber 5130.D – 12½'''
Product Specifications
Analog quartz movement
Line
Caliber
Size
Version
Swiss Made
Swiss Parts
Standard battery life
Hand fitting height
Features
– Repairable metal watch movement
startech
– Very long battery life
5130.D
– Power saving mechanism with pullled out stem: Reduction
of consumption approximately 70%
12½'''
– Very easy handling by two pushers
13 Jewels / gold plated
6 Jewels / nickel plated
48 months
2
Date: 29.06.2018
www.ronda.ch
Page: 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5040.E and is the answer not in the manual?

Questions and answers

Related Manuals for Ronda 5040.E

Summary of Contents for Ronda 5040.E

  • Page 1 RONDA startech 5000 Chronographs, Big Date & Date, different calendar systems, Alarm Caliber 5130.D – 12½''' Product Specifications Features Analog quartz movement – Repairable metal watch movement Line startech – Very long battery life Caliber 5130.D – Power saving mechanism with pullled out stem: Reduction...

  • Page 2: Technical Specifications

    Caliber 5130.D – 12½''' RONDA startech Functions Technical Specifications – 3 eyes Diameter Total 28.60 mm – Chronograph Case fitting 28.00 mm – Chrono-Alarm Movement height 4.40 mm – Center stop second (1/1 Height over standard battery 4.40 mm sec) Movement rest 0.60 mm...
  • Page 3 The indicated angle of the pusher direction and the position must be fullfilled. For pusher angles Sous réserve de modifications of 0° (pusher A and B), see drawing 5000.345. Aenderungen vorbehalten cercle d'entourage RONDA 5130.B, 5130.D Modifications reserved Gehäusering movement holder No. 5000.355...
  • Page 4 Winkel der Drücker A und B 10° Released Angle of pusher A and B Tolerance +/- 20 µm Ø Dp 10° ±2 Scale 10 : 1 (5 : 1) (A3H) 20° Sous réserve de modifications Aenderungen vorbehalten RONDA 4xxx.x, 5xxx.x Modifications reserved No. 5000.345...
  • Page 6 0.06 0.80 0.80 0.03 0.03 0.07 Sous réserve de modifications Aenderungen vorbehalten RONDA 5020.B, 5130.D, 5130.B Inertie / Massenträgheit / Inertia * max. Modifications reserved Force de chassage / Aufpresskraft / Force max. No. 3316.081 * En cas de données différentes, veuillez contacter le service après-vente...
  • Page 7 (dimensions / forces) Artikelnummer Tolerance (min) Part number 10:1 (A3) Scale 3000.040 12.00 1.90 2.60 0.90 0.90 1.35 5010.B, 5020.B, 5021.D, 5030.D, Sous réserve de modifications Aenderungen vorbehalten RONDA 5040.B, 5040.D, 5040.E, 5040.F, Modifications reserved 5050.B, 5050.C, 5051.C, 5130.B, 5130.D 5030.019...
  • Page 8 T2-Instructions 5130.D Fitting dial and hands • Crown in position III • Crown in position II • Install alarm reference time** • Wind hour hand forwards, until • Set date date changes • Crown in position I • Remove working hand • Mount dial • Point all hands towards 12 o’clock • Fit time • Zero chronograph hand* Movement holder Removing setting stem Date switching duration H5XXX.1T First and tenth digit discs ~2hrs General Instructions *Zeroing the Chronograph hand Removing the setting stem can only be effected in Pos.
  • Page 9 You have decided to buy a watch, which was assembled by a watch- 2 beeps  alarm switched on maker using a Ronda movement. Please note that no watches are 1 beep  alarm switched off produced or distributed under the Ronda Brand.
  • Page 10 Put the yellow jumper between the two posts on the closer side. 3622.040 Stator Mark |Z| on stator. 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 11 Train wheel bridge Train wheel bridge held by 3 screws 4000.250. 4000.250 Screw 3715.095.RK Rotor 3147.048.CO Intermediate wheel (counter) 3007.056.CO Minute wheel (counter 24h) 3402.008.CO Minute counting wheel 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 12 Attention: Please hold the coil only on the grey coil core. Coil held by 1 screw 4000.250. 3621.055.RK Coil (counter 6h) Attention: Please hold the coil only on the grey coil core. Coil held by 1 screw 4000.250. 4000.250 Screw 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 13 2130.159.G.M01.5130D Electronic module cover Electronic module cover held by 3 screws 4000.250. 3600.010.HGF Battery 395 3601.109.G Bridle + Bridle held by 1 screw 4000.250. 4000.250 Screw 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 14 Minute train bridge Minute train bridge held by 2 screws 4000.250. 4000.305 Screw 3301.242 Hour wheel (Aig.2) 3315.016 Friction spring 3004.224.CO Date indicator driving wheel 3500.049 Date jumper 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 15 Date mechanism maintaining plate Date mechanism maintaining plate held by 2 screws 4000.250. 4000.250 Screw 3506.072.G Dial support 8200 Moebius 8200 9014 Moebius 9014 Jismaa 124 9020 Moebius 9020 10/2013 N RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 16 -10s/M. .. +20s/M. 1.20 V Lower working voltage limit Setting stem in position III, 60 s measuring interval: 0.10 µA Typical consumption Maximal consumption 0.30 µA 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 1...
  • Page 17 1.68 kΩ .. 1.88 kΩ Coil resistance M4 ∞ kΩ Coil isolation M1/M2/M3/M4 Signal generator (4.9 ms, 8 Hz): Lower working voltage limit 1.20 V M2/M3/M4 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 2...
  • Page 18 Put the yellow jumper between the two posts on the closer side. 3622.040 Stator Mark |Z| on stator. 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 19 Train wheel bridge Train wheel bridge held by 3 screws 4000.250. 4000.250 Screw 3715.095.RK Rotor 3147.048.CO Intermediate wheel (counter) 3007.056.CO Minute wheel (counter 24h) 3402.008.CO Minute counting wheel 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 20 Attention: Please hold the coil only on the grey coil core. Coil held by 1 screw 4000.250. 3621.055.RK Coil (counter 6h) Attention: Please hold the coil only on the grey coil core. Coil held by 1 screw 4000.250. 4000.250 Screw 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 21 2130.159.G.M01.5130D Electronic module cover Electronic module cover held by 3 screws 4000.250. 3600.010.HGF Battery 395 3601.109.G Bridle + Bridle + held by 1 screw 4000.250. 4000.250 Screw 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 22 Minute train bridge Minute train bridge held by 2 screws 4000.250. 4000.305 Screw 3301.242 Hour wheel (Aig.2) 3315.016 Friction spring 3004.224.CO Date indicator driving wheel 3500.049 Date jumper 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 23 Date mechanism maintaining plate Date mechanism maintaining plate held by 2 screws 4000.250. 4000.250 Screw 3506.072.G Dial support 8200 Moebius 8200 9014 Moebius 9014 Jismaa 124 9020 Moebius 9020 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
  • Page 24 -10s/M. .. +20s/M. 1.20 V Lower working voltage limit Setting stem in position III, 60 s measuring interval: 0.10 µA Typical consumption Maximal consumption 0.30 µA 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 1...
  • Page 25 1.68 kΩ .. 1.88 kΩ Coil resistance M4 ∞ kΩ Coil isolation M1/M2/M3/M4 Signal generator (4.9 ms, 8 Hz): Lower working voltage limit 1.20 V M2/M3/M4 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 2...
