5. CONTROLS AND INDICATORS

6. DEVICES INSTALLATION

Fig. 6 - NEXT K9-85 MCW INSTALLATION
2
Push catch and remove board
1
On surface
Notes
1. Keep away from heat sources.
2. Do not expose to air drafts.
3. Do not install outdoors.
4. Avoid direct sunshine.
5. Keep wiring away from power cables.
6. Do not install behind partitions.
7. Mount on solid stable surface
4
DISPLAY
Figure 5 - Controls & Indicators
3
Insert battery
Front Tamper switch
Back Tamper switch (option)
Release screw and
remove cover
4
Mounting
In corner
POWER
NEXT
EMERGENCY
(Hold for 2 sec.)
VOLUME UP (*)
RECORD MESSAGE (*)
VOLUME DOWN (*)
PLAY MESSAGE (*)
MUTE SPEAKER (*) (**)
CHIME ON/OFF
EVENT LOG
CANCEL ENTRY DELAY
Fig. 7 - MCT-320 INSTALLATION
1
Remove spacer
Note
It is highly recommended to attach the transmitter to the top
of the door/window on the fixed frame and the magnet to the
movable part (door or window). Make sure that the magnet is
located not more than 6 mm (0.25 in.) from the transmitter's
marked side.
Pressing both AWAY + HOME
initiates a PANIC alarm.
INDICATORS
ARM CHIME TROUBLE
SHOW/OK
Press both
for panic
FIRE (Hold
alarm
for 2 sec.)
ARMING "AWAY"
PGM OUTPUT ON
ARMING "HOME"
PGM OUTPUT OFF
DISARMING
PGM CONTROL
MOVE BACK
PARTITION
Magnet
3mm
spacer
A. Fasten the spacer to mounting
surface with 2 screws.
B. Locate the magnet on the
spacer at the correct direction and
push it upward.
Fig. 8 - MCT-234 USAGE
2
DISARM
AWAY
HOME
AUX
D-302887
