2. BACK-UP BATTERY INSERTION

Front unit
Battery cable
Figure 2 - Battery Insertion

3. MOUNTING ON A WALL

Back unit
1
3
Release
Mark 4 drilling points on mounting surface
screws
5
4
Fasten the back unit with 4 screws
Drill 4 holes and insert wall anchors
Figure 3 - Mounting on a Wall
2
D-302887
