ELECTRONIC SCALE
EQB/EQM
SERIES
OWNER'S MANUAL
BASCULA ELECTRONICA
EQB/EQM
SERIE
MANUAL DE USUARIO
REVISION:1.2
IMPORTANT:
BEFORE OPERATING THIS SCALE, PLEASE READ THIS MANUAL THOROUGHLY.
ANTES DE OPERAR SU BASCULA, FAVOR DE LEER ESTE MANUAL CUIDADOSAMENTE.
Advertisement
Table of Contents
Related Manuals for Torrey EQM Series
Summarization of Contents
Important Safety Warnings
Problem Handling and Warranty
Read warranty conditions first if scale has a problem. Unauthorized opening voids warranty.
Keyboard and Cleaning Precautions
Avoid pressing the keyboard with sharp objects and never wash the scale with water flow.
Environmental and Usage Guidelines
Protect from insects, avoid dropping products, and use only damp rags for cleaning.
Installation and Setup
Scale Unpacking and Turret Installation
Unpack the scale and install the turret by following the provided steps and diagrams.
Fence Installation and Placement
Install the protective fence using screws and nuts, and ensure the scale is placed on a stable surface.
Power Connection and Scale Activation
Connect the AC/DC power supply and turn on the scale after the countdown sequence.
Parts Identification
Front View Components
Identify major scale components such as wheels, base, plate holder, turret, and display.
Keyboard Layout and Functions
Power and Unit Control Keys
Learn to use the ON/OFF keys and the Kg/Lb key for unit conversion.
Zero and Tare Function Keys
Understand the ZERO key for resetting and the TARE key for container weight elimination.
Display and Printer Interface Keys
Control backlight, send data to printer, and identify the general view finder.
Display Indicators and Messages
Alphanumeric and Battery Indicators
Understand the alphanumeric display for weight and messages, and the low battery warning.
Zero, Tare, and Power Indicators
Recognize indicators for zero readiness, tare activation, and AC/DC power connection.
Basic Operation Procedures
Weighing a Product
Turn on the scale, wait for zero, place the product, and read the weight.
Using the Tare Function
Subtract container weight before measuring the product's net weight.
Advanced Operation Features
Tare Function Details and Limitations
Understand subtractive nature, negative weight indicators, and how to cancel tare.
Unit Conversion Functionality
Demonstrates switching between kilograms (kg) and pounds (lb) for weighing.
Scale Functions and Battery
Reference to Zero Adjustment
Reset the scale to zero to compensate for voltage variations or handling.
Backlight and Auto Power Off
Use the backlight for visibility and understand the auto power-off function for energy saving.
Battery Operation and Recharge
Operate with battery or AC/DC supply; recharge battery for up to 30 hours of use.
Battery Life and Charging
Rechargeable Battery Lifecycle
Battery capacity decreases with cycles; service life limited to 1000 cycles.
Low Battery Indicator and Usage
Low battery signals need for recharge; scale stops if ignored.
Car Lighter Power Connection
Optional connection to a car's 12-volt lighter for portable power.
Scale Counters and Calibration
Counter Verification Function
Scale has calibration and configuration counters accessible by inspectors.
Accessing Scale Counters
Instructions to check calibration and configuration counters using specific key presses.
Scale Error Messages
Overload and Help Messages
Understand 'OVERLOAD' for excess weight and 'HELP' for operational issues or shipping damage.
Negative Weight Indication
Interpret the 'NEG.' message, often due to plate lifting, and how to correct it.
Maintenance and Cleaning Guidelines
Scale Cleaning Procedures
Use a damp rag for daily cleaning; avoid water flow, detergents, and corrosive liquids.
Operational Environment and Checks
Avoid moisture/dust, check for obstructions under the plate, and ensure levelness.
Component Care and Handling
Periodically check power supply, avoid extreme temperatures, and never press keys with objects.
Troubleshooting Guide
Scale Not Operating
Check power, outlets, and cable connections if the scale does not turn on.
Inconsistent Weight Readings
Resolve inconsistent weights by checking for obstructions under the plate holder.
Error Messages Resolution
Correct 'HELP' or 'UNLOAD' messages by removing weight or resetting the scale.
Technical Specifications
Model Capacity and Division
Details on maximum capacity, minimum division, and tare limits for various models.
Operating and Storage Temperatures
Specifies the operational and storage temperature ranges for the scale.
Power Supply and Serial Number
Information on AC/DC power supply requirements and locating the product serial number.
