800 lb. Maximum Capacity Payload
asseMBly and oPeraTion insTruCTions
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
saVe THis Manual.
Copyright
2003, 2007 by Harbor Freight Tools
©
this manual or any artwork contained herein may be reproduced in any shape or
form without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Box Trailer
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
Manual revised 04j, 07f, 09b
02948
IMPORTANT INFORMATION
This trailer's Hitch Coupler MUST be
properly secured to the hitch ball of the towing
vehicle. After assembly and attachment, pull
up and down on the Hitch Coupler to make
sure the hitch ball is fitting snugly in the Hitch
Coupler. There must be no play between the
hitch ball and Hitch Coupler. If there is play,
tighten the Adjustment Nut until no play is
present. If the Adjustment Nut is too tight, the
Handle will not lock. Carefully read and follow
the complete instructions in this manual
BEFORE setup or use.
If the Coupler is not secured
properly, the ball could come loose
while the trailer is in motion, possibly
causing property damage, SERIOUS
PERSONAL INJURY, or DEATH.
. All rights reserved. No portion of
®
WARNING!
.
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAUL MASTER 2948
Summary of Contents for HAUL MASTER 2948
- Page 1 Box Trailer 800 lb. Maximum Capacity Payload Model 02948 asseMBly and oPeraTion insTruCTions WARNING! IMPORTANT INFORMATION This trailer’s Hitch Coupler MUST be properly secured to the hitch ball of the towing vehicle. After assembly and attachment, pull up and down on the Hitch Coupler to make sure the hitch ball is fitting snugly in the Hitch Coupler.
-
Page 2: Table Of Contents
ConTenTs sPeCiFiCaTions ..................3 General saFeTy WarninGs and PreCauTions ......3 sPeCiFiC ProduCT WarninGs and PreCauTions ..... 4 unPaCKinG .................... 5 asseMBly insTruCTions ..............6 To assemble the Tires, Wheels, and axle:............6 To assemble the Frame, Tongue, and Hitch Coupler: ........8 To attach the axle/Tire assembly to the springs: ..........9 To attach the Tail light Bracket: ................10 To attach the Tail light/Wire set: ...............10... -
Page 3: Specifications
sPeCiFiCaTions Maximum Payload Capacity 800 lbs. Hitch Coupler Requirements Class 1 / 1200 Pounds Load Capacity / 2-1/2” Tongue / 1-7/8” Ball Overall Dimensions 82” L x 51-1/8” W x 30-1/2” H Trailer Bed Dimensions 55” L x 35” W x 1/2” Thick Front/Side Panels/Tail Gate Height 12-7/8”... -
Page 4: Specific Product Warnings And Precautions
dress saFely. Do not wear loose clothing or jewelry, as they can become caught in moving parts. Wear a protective hair covering to prevent long hair from becoming caught in moving parts. If wearing a long-sleeve shirt, roll sleeves up above elbows. -
Page 5: Unpacking
Bends, and any oTHer CondiTion THaT May aFFeCT iTs saFe oPera- Tion. Do not use the Trailer even if minor damage appears. neVer alloW adulTs, CHildren, or PeTs To ride in THe Trailer. BeFore eaCH use, alWays aTTaCH THe saFeTy CHain (a19) oF THe Trailer To THe ToWinG VeHiCle. -
Page 6: Assembly Instructions
asseMBly insTruCTions note: For additional references to the parts listed below, refer to the assembly diagram near the end of this manual. To assemble the Tires, Wheels, and axle: iMPorTanT! Whenever a Hub (a9) on a new unit requires assembly (or a Hub is disassembled for maintenance), the following procedures MusT be followed: Using a suitable solvent, thoroughly clean the Bearings (A9), Seal (A9), Castle Nut... - Page 7 CoTTer Pin (10) axle (a8) luG nuT luG nuT (9) HuB (a9) BearinGs (a9) FlaT WasHer (a9) Tire & riM (a15) CasTle nuT (11) CaP (a9) FiGure a Carefully slide the Hubs (A9) over the Spindles at each end of the Axle (A8). Insert the Bearings (A9) and the Flat Washer (A9) on the Spindles.
-
Page 8: To Assemble The Frame, Tongue, And Hitch Coupler
To assemble the Frame, Tongue, and Hitch Coupler: FiGure B FraMe (a1) riGHT side BraCe (a18) leFT side BraCe (a17) ToW Bar (a13) HiTCH CouPler (a14) BolT BolT sPrinG sPrinG WasHer saFeTy WasHer CHain loCK nuT (a19) loCK nuT On a flat, level, surface lay out the Frame (A1), Right Side Brace (A18), Left Side Brace (A17), Tow Bar (A13), Hitch Coupler (A14), and Safety Chain (A19). -
Page 9: To Attach The Axle/Tire Assembly To The Springs
To attach the axle/Tire assembly to the springs: FraMe (a1) sPrinG HanGer Pin (7) loCK nuT (7) BolT (7) loCK nuT (8) sPrinG PlaTe (a20) sPrinG (a10) u-BolT (8) axle (a8) FiGure C Align the mounting hole at each end of a Spring (A10) with the mounting holes in the two Spring Hangers located in one side of the Frame (A1). -
Page 10: To Attach The Tail Light Bracket
To attach the Tail light Bracket: Align the two mounting holes in a Tail Light Bracket (A7) with the two mounting holes located in the side, rear section of the Frame (A1). Then secure the Tail Light Bracket to the Frame, using two Bolts, two Spring Washers, and two Nuts (3). Repeat this procedure to attach the remaining Tail Light Bracket to the other side of the Frame. -
Page 11: To Attach The Fenders
To attach the Fenders: Align the two mounting holes in a Fender (A16) with the two mounting holes located midway along one side of the Frame (A1). Then secure the Fender to the side of the Frame, using two Bolts, two Spring Washers, and two Nuts (6). Repeat this procedure to attach the remaining Fender to the other side of the Frame. -
Page 12: Operating Instructions
Tail GaTe (a6) loCK Handle loCK Handle leFT riGHT side side Panel Panel (a2) (a3) PronG PronG FraMe FraMe FraMe (a1) MounTinG sloT MounTinG sloT FiGure e Raise the Lock Handles on the rear of the Left Side Panel (A2) and Right Side Panel (A3). - Page 13 HiTCH CouPler TriGGer (a14) “r” Pin Handle saFeTy saFeTy CHain adJusTMenT (a19) ToWinG VeHiCle rear BuMPer or FraMe 1-7/8” HiTCH Ball FiGure F (noT inCluded) Temporarily remove the “R” Pin and Safety Pin. Then, pull up on the Trigger and lift up on the Handle.
-
Page 14: Tire Information
Tire inForMaTion Tire Terminology Glossary • accessory weight means - the combined weight of automatic transmission, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment. • Carcass means - the tire structure except for the tread which provides the major portion of the tire’s capability to deflect in response to the vertical loads and tractive forces that the tire transmits from the roadway to the non-pneumatic rim, the wheel center member, or the vehicle and which attaches to the... -
Page 15: Tire Markings
Tire Markings inner diameter load index and in inches speed rating* european tire section width certificate* in inches u.s. doT tire identification number Tire ply composition and materials used Maximum permissible inflation pressure Maximum load rating Trailer *information not required by u.s. doT tire •... -
Page 16: Tire Inflation And Load Limit
• speed rating- The speed rating denotes the speed at which a tire is designed to be driven for ex- tended periods of time. This does not indicate that the Tire speed rating Codes vehicle or rims can safely reach or maintain that speed. Code MPH Code MPH Code MPH... -
Page 17: Tire Care
Tire Care Checking Tire Pressure note: Underinflated tires can decrease handling, stopping performance, traction, tire life, and load-carrying capability, in addition to causing other negative and hazardous effects, including tire failure. Overinflated tires are at greater risk of an impact break, where the tread and casing break when striking a hard edge, often opening a huge gash across the tread. -
Page 18: Tire Size
Check all the tires to make sure they have the same air pressure. If the tires’ pressure was not measured “cold”, then the pressure should be rechecked with the tires cold as soon as possible. Tire size To maintain safety, only purchase new tires of the same size as the original tires. Look at the Tire and Loading Information Placard, the Specifications Chart in this manual, or the sidewall of the tire being replaced. -
Page 19: Vehicle Load Limit
VeHiCle load liMiT steps for determining Correct load limit Locate the statement “The weight of cargo should never exceed XXX kilograms or XXX pounds” on your vehicle’s placard. That figure equals the available amount of cargo and luggage load capacity. Determine the combined weight of luggage and cargo being loaded on the vehicle. -
Page 20: Parts Lists And Diagrams
ParTs lisTs and diaGraMs Please read THe FolloWinG CareFully THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEI- THER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 21: Assembly Diagram
assembly diagram reV 05b SKU 02948 For technical questions, please call 1-800-444-3353. Page 21... -
Page 22: Wiring Diagram For Lights
Wiring diagram for lights reV 03d SKU 02948 For technical questions, please call 1-800-444-3353. Page 22... - Page 23 liMiTed 90 day WarranTy Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
