  • Page 1 TRAILER FOLDABLE - WITH 12” WHEELS MODEL 95419 ASSEMBLY AND OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http//www.harborfreight.com Copyright 2006 by Harbor Freight Tools . All rights reserved. No portion of this ©...

  • Page 2: Product Specifications

    DO NOT USE THIS PRODUCT IF UNDER THE INFLUENCE OF ALCOHOL OR DRUGS. Read warning labels on prescriptions to determine if your judgement or SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 2...
  • Page 3 The opera- tor must understand that common sense and caution are factors, which cannot be built into this product, but must be supplied by the operator. SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 3...

  • Page 4: Specific Product Warnings And Precautions

    WHENEVER POSSIBLE, PARK THE TRAILER ON A FLAT, LEVEL, PAVED, SURFACE AND CHOCK BOTH TIRES TO KEEP THE TRAILER FROM ACCIDENTLY MOVING. TRAILER LICENSING NOTICE: Some states may consider this Trailer a vehicle SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 4...

  • Page 5: Assembly Instructions

    3/8” x 3/4” Bolts (A), 3/8” Nylon Nuts (G) and also the 3/8” x 1” Bolts (B) and 3/8” Nylon Nuts (G). (See Figure A.) TO CENTER OF TRAILER TO FRONT OF TRAILER FIGURE A SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 5...
  • Page 6 Assemble the front portion and the rear portion of the Trailer, using the 3/8” x 3/4” Bolts (A), 3/8” Nylon Nuts (G). Then, fold the Trailer. (See Figure D, next page.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 6...
  • Page 7 Left Side Rail (1FL), using 3/8” x 1” Bolts (B) and 3/8” Nylon Nuts (G). Attach the Spring Hanger (12R) to the Front Right Side Rail (1FR), using 3/8” x 1” Bolts (B) and 3/8” Nylon Nuts (G). (See Figure E.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 7...
  • Page 8 Then secure the Axle and Spring assemblies, using 3/8” Spring Washers (L) and 3/8” Nylon Nuts (G). After doing this, tighten the Bolts (E) and Nuts (I) left loose in the last step. (See Figure F.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 8...
  • Page 9 Attach the Coupler (7) to the Coupler Base (6), using a 3/8” x 3-1/2” Bolt (W). Lock the Coupler Trigger with the Safety Pin (29). Then, insert the “R” Pin (S) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 9...
  • Page 10 Tail Light (28L) to the Tail Light Bracket, using 3/8” Nylon Nuts (G). Repeat this Step for the remaining Tail Light Bracket and Rear Right Side Rail (1RR). (See Figure H.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 10...
  • Page 11 Side Running Light (24) located on the Front Left Side Rail (1FL). Then, run the Green/Brown Wires along the inside of the Front Right Side Rail (1FR) to the other Side Running Light. (See Figure I.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 11...
  • Page 12 SIDE RUNNING LIGHT (24) (24) LEAVE 16” EXCESS WIRE HERE. LEAVE 16” EXCESS WIRE HERE. YELLOW GREEN BROWN BROWN BLACK BLACK FIGURE I RIGHT TAIL LIGHT (28R) LEFT TAIL LIGHT (28L) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 12...
  • Page 13 Latches (9) and fold the Trailer Tongue down. (See Figure J.) NOTE: To avoid damage to Casters (13), avoid rolling the Trailer on its Casters over long distances. FIGURE J SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 13...
  • Page 14 4.37 18.9 13.96 13.96 18.9 9.29 4.37 9.29 13.96 14.35 0.75 4.37 18.9 18.9 3/8” CROSS HEAD BOLT 4.37 3/8” FLAT WASHER 3/8” SPRING WASHER 3/8” HEX NUT FIGURE K SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 14...
  • Page 15 (See Figure L, and Figure M.) 3/8” DIAMETER STAKE 1.25 FRONT END BACK END RAIL SIDE RAIL 3/8” DIAMETER 18.5825 50.835 18.5825 1.25 94.5 3/8” DIAMETER CONNECTING PLATE FIGURE L SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 15...

  • Page 16: Operating Instructions

    Note: Be sure to read Bearing Packing Instructions on the last page of this manual. Only use a 1-7/8” ball hitch (not included) on the towing vehicle. (See Figure N, next page.) SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 16...
  • Page 17 NOTE: Make sure to consult the operator’s manual of the towing vehicle for proper connection instructions. TRIGGER “R” PIN (S) HANDLE SAFETY PIN (29) ADJUSTMENT HITCH COUPLER (7) SAFETY HITCH BALL CHAIN (NOT INCLUDED) FIGURE N SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 17...

  • Page 18: Inspection, Maintenance, And Cleaning

    ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 18...

  • Page 19: Parts List

    3 mm “R” Pin Bearing 4 mm Self Tapping Screw Dust Cap 2 mm “R” Pin Fender Nylon Nut M8 Fender Seat Side Running Light Bolt M10 x 90 Stake Clamp SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 19...

  • Page 20: Assembly Diagram

    Hotline. Note: Check with your local department of Motor Vehicles for registration procedures. Some DMV’s require the Certificate of Origin to be notarized, others do not. SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 20...

  • Page 21: Wiring Diagram

    WIRING DIAGRAM NOTE: Some trailer tail lights will have two leads instead of three. They connect to the harness leads the same way; brown to brown, color to color. SKU 95419 For technical questions, please call 1-800-444-3353. PAGE 21...

  • Page 22: Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 95419 For technical questions, please call 1-800-444-3353.
