Summarization of Contents
Chapter 1 Introduction
Specifications
Details the physical dimensions, electrical ratings, environmental conditions, and regulatory compliance of the stretchers.
Model Identification
Lists the different stretcher model numbers and their corresponding descriptions.
Safety Tips
Provides essential safety guidelines for operating and maintaining the stretchers.
Warning and Caution Labels
Illustrates and explains various warning and caution labels found on the stretcher.
Chapter 2 Troubleshooting Procedures
Getting Started
Initial steps and warnings before beginning troubleshooting procedures.
Initial Actions
Steps to gather information about the problem from the operator.
Scale—Problem and Solution Table
Troubleshooting table for scale display errors, linking problems to specific RAP procedures.
Function Checks
Procedures to verify the correct operation of key stretcher functions.
Reduced Braking Ability
Troubleshooting steps for issues related to reduced or ineffective braking.
Loss of Corner Steer
Troubleshooting procedure for issues with the corner steer function.
Scale Display Does Not Come On
Troubleshooting steps when the scale display is not functioning.
Chapter 3 Theory of Operation
Electrical System (Electric Stretcher)
Explains the electrical components and operation of the electric stretcher.
Electric Stretcher Wiring Diagrams
Provides schematic wiring diagrams for the electric stretcher.
Scale System (Optional for the Procedural, Electric, and Trauma Stretchers)
Details the operation and components of the optional scale system.
Chapter 4 Removal, Replacement, and Adjustment Procedures
Tool and Supply Requirements
Lists the necessary tools and supplies for performing procedures.
Procedural (P8000), Surgical (P8010), Trauma (P8040), or OB/GYN (P8050) Stretcher—Siderail
Instructions for removing and replacing the siderail on specific stretcher models.
Electric (P8020) Stretcher—Siderail
Detailed steps for removing and replacing the siderail on electric stretchers.
Electric (P8020) Stretcher—Control Board
Steps for removing and replacing the control board on the electric stretcher.
Caster
Procedure for removing and replacing casters on the stretcher.
Hydraulic Cylinder
Instructions for removing, replacing, and adjusting hydraulic cylinders.
Scale—Load Beam
Instructions for removing and replacing the load beams in the scale system.
Chapter 5 Parts List
Service Parts Ordering
Information on identifying and ordering replacement parts using part numbers.
Exchange Policy
Details Hill-Rom's policies for in-warranty and out-of-warranty part exchanges.
Warranty
Outlines the limited warranty terms and conditions for stretchers and accessories.
Recommended Spare Parts
Provides a list of recommended spare parts for servicing multiple units.
Caster and Base Shroud
Illustrated parts list for the caster and base shroud assembly.
Base Assembly—Side Pedal
Illustrated parts list for the base assembly with side pedals.
Upper Frame Assembly—Transport (P8005) Stretcher
Illustrated parts list for the upper frame assembly of the Transport stretcher.
Electric (P8020) Stretcher—Control Board Assembly (120 V AC and 230 V AC)
Illustrated parts list for the electric stretcher control board assembly.
Chapter 6 General Procedures
Cleaning and Care
Provides instructions and precautions for cleaning and maintaining the stretcher.
Component Handling (Electric Stretcher and Stretchers with the Scale Option)
Cautions for handling PC boards and electronic components, emphasizing antistatic precautions.
Preventive Maintenance
Emphasizes the necessity of an effective maintenance program for stretcher longevity.
Preventive Maintenance Schedule
Outlines a schedule for preventive maintenance checks on various stretcher functions.
Preventive Maintenance Checklist
A checklist to record and track preventive maintenance tasks and their outcomes.
Chapter 7 Accessories
Stretcher Accessories
Lists various optional accessories available for stretchers.
7.1 Infusion Support System (ISS) Transfer Pole (P158)
Instructions for installing the ISS Transfer Pole (P158).
7.5 Footboard (P4120CTM07)
Instructions for mounting and using the footboard as a stretcher extender.
7.10 Push Handles
Instructions for installing the push handles for caregiver control during transport.
7.21 Gas Delivery System (P263)
Instructions for installing, using, and cleaning the gas delivery system.
7.24 Telescoping Calf Supports (P35745AT)
Instructions for installing, adjusting, and storing calf supports for birthing position.
7.25 Integrated Fiber Optic Exam Light (P7915AT)
Instructions for installing and cleaning the integrated fiber optic exam light assembly.
