To see information about the profile in use,
click Active Profile to bring up the next
screen.
This screen contains information about your
modem's current configuration. Starting from
the top, you will see the make and model of
your modem. Directly below that, you will see
basic commands currently in use followed by
the current connection settings.
84
U M S
SING ODEM TATION
The two lines below the connection settings are
the advanced commands currently in use.
Below them is a display of the contents of the
'S-Registers' for your modem. These registers
are special programmable areas of your
modem's memory. They are used to store
commands that are too complex to be handled
by the standard (or 'AT') commands. Just
below that you will see the last number dialed.
The next option displays the "Stored Profile"
screen. This screen shows the configuration
stored in your modem's NVRAM (special
programmable memory). Note that any stored
phone numbers are displayed on this screen as
well.
The next two screens contain information that
our technical support representatives may need
if you request support.
