0x1C Custom Control Name Dump
This dump, which is both transmitted and received by the PCM 90, contains all of the name strings for a
single custom controller. Only strings which will actually be displayed are meaningful. If the settings of the
controller max, min and mid points do not provide for the display of a label (such as Hi label), only a dummy
string will be transmitted by the PCM 90. If such a string is sent to the PCM 90, it will not be saved with
the effect.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x1C
6 0000 0iii
7- 26 0iii iiii
27- 42 0iii iiii
43- 58 0iii iiii
59- 74 0iii iiii
75- 90 0iii iiii
91- 106 0iii iiii
107 0xF7
0x1D KeyWord Dump
This dump, which is both transmitted and received by the PCM 90,contains all of the KeyWord indices for
the current effect.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x1D
6- 9 0iii iiii
10 0xF7
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Custom Names
Control ID
ASCII Name of controller
ASCII label for values
between mid and max
(HighRange)
ASCII label for values
between min and mid
(LowRange)
ASCII label for max value
(HighLabel)
ASCII label for midpoint
value (MidLabel)
ASCII label for min value
(LowLabel)
End of SysEx
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
KeyWords
KeyWord indices
End of SysEx
PCM 90 MIDI Implementation Details
Notes
0-3=Custom Controls; 4=Adjust Knob
20 byte string
16 byte string
16 byte string
16 byte string
16 byte string
16 byte string
Notes
See Appendix B: KeyWords.
21
