PCM 90 MIDI Implementation Details
0x07 Chain Element Dump
This is a bidirectional dump which describes a single position in a program chain.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x7
6 0iii iiii
7 0iii iiii
8 0iii iiii
9 0iii iiii
10 0xF7
0x08 Display Dump
When sent from the PCM 90, this bidirectional dump holds the current display information, whatever it is.
When sent to the PCM 90, this text is displayed for 2 seconds.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x08
6-25 0iii iiii
26-45 0iii iiii
46 0xF7
12
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Chain Element Data
Chain #
Offset in chain
Bank
Offset
End of SysEx
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Display message
Top line of display
Bottom line of display
End of SysEx
Notes
0- 9
Any legitimate Bank index. See Appendix C: MIDI Bank
Assignments. If nothing is assigned to this position in the
table, a value of 0x7F is returned.
0 - 49
Notes
20-byte copy of upper display line.
20-byte copy of lower display line.
Lexicon
