0x18 System Setup Dump
This dump, which is both transmitted and received by the PCM 90, contains all system parameters (those
parameters that are not part of a preset).
Note that when the PCM 90 receives a current setup (0x7F) it ignores parameter #10 (device ID) and
parameter #11 (SysEx enable). Those values can only be changed from the front panel or by restoring
a setup from internal memory or card.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x18
6 0iii iiii
7-15 0iii iiii
16-19 0n
20-215 0n
216
0x19 Save Current Edit Buffer Message
Host to PCM 90 only. The current edit buffer is named and saved with this message.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x19
6 0iii iiii
7 0iii iiii
8-19 0iii iiii
20 0xF7
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Setup Data
Setup ID
Setup name
Nibble-ized unsigned
short param value
(LS first) for first param
Remaining params
0xF7
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Save Code
Destination Bank
Destination Program
12-character program name
End of SysEx
PCM 90 MIDI Implementation Details
Notes
0x7F=Current; 0-4=Internal; 5-9=RAM Card. A RAM card
may be detected using the Configuration Response.
See Overview for information on ASCII characters.
These parameters correspond by index with Type 0 System
parameters. The SysEx packet is sized to hold 50 such
parameters. The actual count of system parameters is 43, so
the remaining parameter slots should be regarded as re-
served and set to zero. The ranges for the parameters are
listed in Appendix F: System (Type 0) Parameters.
End of SysEx
Notes
Must be a writeable register or card bank. If a card bank, the
write-protect tab must be off. See Appendix C: MIDI Bank
Assignments.
0 - 49
See Overview for information on ASCII characters.
19
