Owner's Manual Addendum

Viewing and Editing LXP-1 Setup Parameters

LXP-1 setup parameters are viewed and edited on two MRC display pages.
Pages can be selected by pressing PAGE repeatedly, or by pressing the
desired page number on the keypad.
To edit LXP-1 parameters from the MRC, simply select the desired page and
move the slider of the parameter you want to edit. The new value is displayed
on the MRC and transmitted to the LXP-1. (You will see the MIDI LED flicker
when sliders are moved on the MRC.) Refer to the MRC V3.0 Owner's
Manual for a complete description of how to use the MRC to edit LXP-1 setup
parameters.
Using the and ENTER Keys
While in Machine Run Mode, the
parameters to the LXP-1. Use it to reset the LXP-1 to the values displayed
by the MRC. (You would do this, for example, if LXP-1 parameters are
inadvertently changed from its front panel.) If you are using two-way
communication, you can press ENTER to update the MRC to the current
parameter values of the LXP-1. This allows you to transfer new settings to
the MRC after front panel adjustment of the LXP-1.

Storing Setups from Machine Run Mode

You can store a setup you've created in any one of the MRC's sixteen
internal setups, or in any one of the LXP-1's 128 user registers. Here's how:
1. On the MRC, press STORE to enter Setup Store Mode.
2. Move slider 2 to select "MRC SETUP" or "LXP-1 RGSTR"
3. Use slider 1, the SETUP key or the keypad to select a setup number.
(The display will blink if you enter an invalid number. Valid numbers for
MRC setups are 1–16. For LXP-1 registers valid numbers are 1–128.)
4. Press ENTER to store the setup and return to Machine Run Mode
OR
Press MACH to exit Setup Store Mode and return to Machine Run Mode
without storing the setup.
Controlling the LXP-1 with Two-Way Communication
key transmits the current values of all
5-9
