Overview of One-way Features

Foot Pedal #1
Foot Pedal #2
• Simplified MIDI set up
• MRC editing and display of parameter settings for multiple LXP devices
• Multiple LXPs can be controlled from a single MRC output via the MIDI
THRU ports on the LXPs
• MIDI clock can be routed to LXPs for Tempo patching
• Both MRC inputs can be used to route MIDI controllers to LXP internal
MIDI patches
• Each LXP being controlled can have any four of its parameters controlled
by the MRC's internal MIDI patches
• MRC's GMIDI machines can control other MIDI devices while MRC is
actively editing LXP parameters
Controlling the LXP Series of Multi-Effects Processors
Additional LXPs
or MIDI devices
THRU
LXP-15
(Tempo
Control)
Sequencer,
Keyboards, etc.
LXP-5
2 1 2 1 2 1
EXT OUT IN
MRC
MIDI
Clock
2-5
