5. Controlling the LXP-1 with

Two-Way Communication

Two-way Connections

Two way communication allows you to access and view parameters stored
in the LXP-1's 128 internal registers. You can connect one or two LXP-1s to
the MRC for two-way communication. Two MIDI cables are required for each
LXP-1. The LXP-1 MIDI OUT and MIDI IN can be connected to the MRC IN1
and OUT1 or MRC IN2 and OUT2. Be sure the THRU port on the back of the
LXP-1 has been changed to an"OUT" port. This requires that an internal
jumper be changed in the LXP-1. Instructions for changing this jumper are
given at the end of this chapter.

Merging and Two-way Communication

2 1 2 1
OUT
EXT
MRC
When connected for two-way communication, the merging function for the
input port connect to the LXP-1 must be set to "OFF" (If it is set to "ON,"
communication will not be possible and the MRC will display "SYNCH
TIMEOUT" )
Controlling the LXP-1 with Two-Way Communication
2 1
LXP-1
IN
Internal
jumper must be
set to "OUT"
5-1
