Two-way Control of Multiple LXP-5s

LXP-5
can be patched to
LXP machines
controlling both
LXP-5s
Using two-way communication you can control two LXP-5s at once, one for
each input/output pair. If you have a high quality MIDI merger you can control
multiple LXP-5s on the same input/output pair. (Each LXP-5 and its
corresponding MRC machine must be assigned to a different MIDI channel.)
As long as the LXP-5 MIDI OUT is connected to the appropriate MRC IN you
can maintain two-way communication with it, even if other devices are daisy
chained to the MRC OUT. This is useful, for instance, when you want to
control the LXP-5 and one or more sound modules from a sequencer or
keyboard. (See illustration.)
Controlling the LXP-5 with Two-Way Communication
T
H
R
U
2 1 2 1 2 1
OUT IN
EXT
MRC
Other MIDI
devices
LXP-5
4-5
