(Mac ® ) - Lexicon I-ONIX U22 Owner's Manual

Set Up Cubase LE 4 for Use with the I•ONIX U22
(Mac )
®
1. Make sure the included USB cable is connected to your computer and to
the U22, the Mixer is open, and the U22 is turned on.
2. Open Cubase LE 4 (located in the Applications folder), and go to
Devices>Device Setup as shown below.
3. Click VST Audio System and select Lexicon I-ONIX U22 as the ASIO
Driver if it is not already selected.
4. Cubase LE 4 will now ask you if you would like to switch the driver.
®
Select Switch then OK.
Mac OS 10.4.x users only: After selecting Lexicon I•ONIX U22 as the
®
ASIO Driver, you may need to verify that your device inputs are active. To
do this, follow these steps:
1. Select Device>VST Connections from the menu bar.
2. When the VST Connections panel appears, click the
3. The box under the Audio Device column may say "
it does, click in this box and select Lexicon I-ONIX U22 to enable the
U22 inputs.
4. Close the VST Connections window.
You are now ready to start recording with Cubase LE 4, described in the
next section,
Inputs tab.
Not Connected". If
15
