Set Up Cubase LE 4 for Use with the I•ONIX U22
®
(Windows )
®
1. Make sure the included USB cable is connected to your computer and to
the U22 and the U22 is turned on.
2. Start Cubase ® LE 4 (from the Start menu under Lexicon
3. If you see the warning shown below, click OK.
4. Once you are in Cubase LE 4, go to Devices>Device Setup.
5. Under Devices, click on VST Audio System and select Lexicon I-ONIX
U22 from the ASIO Driver pull-down menu if it is not already selected.
Click on Switch to switch the driver, then click OK in the Device Setup
dialog. You are now ready to begin recording using your U22 and
Cubase LE 4.
Note: In many cases you can improve performance by selecting a higher
latency setting from the System Performance drop-down menu on the ASIO
control panel (Devices > Device Setup > Lexicon I-ONIX U22 > Control
Panel > ASIO).
® ).
