Set Up Cubase Le 4 For Use With The I•Onix U42S (Mac ® ) - Lexicon I-ONIX U42S Owner's Manual

Set Up Cubase LE 4 for Use with the I•ONIX U42S
(Mac )
®
1. Make sure the included USB cable is connected to your computer and to
the U42S, the Mixer is open, and the U42S is turned on.
2. Open Cubase LE 4 (located in the Applications folder), and go to
Devices>Device Setup as shown below.
3. Click VST Audio System and select Lexicon I•ONIX U42s as the ASIO
Driver if it is not already selected.
4. Cubase LE 4 will now ask you if you would like to switch the driver.
®
Select Switch then OK.
5. Ensure the driver is loaded by clicking Reset. Then click OK.
Mac OS 10.4.x users only: After selecting Lexicon I•ONIX U42s as the
®
ASIO Driver, you may need to verify that your device inputs are active. To
do this, follow these steps:
Device>VST Connections from the menu bar.
1. Select
2. When the VST Connections panel appears, click the
3. The box under the Audio Device column may say "
it does, click in this box and select Lexicon I•ONIX U42s to enable the
U42S inputs.
4. Close the VST Connections window.
You are now ready to start recording with Cubase LE 4, described in the
next section,
Inputs tab.
Not Connected". If
17
