Menu Mode - Yaesu FTM-10R - QUICK CODE SHEET Manual

Press and hold the [ VOL/SEL ] key for one second to enter to the Menu Mode while the VFO mode or Memory mode.
Display
Enables/Disables the Automatic Audio Volume Controller.
F 1 AF AUTO
Enables/Disables the AF DUAL operation.
F 2 AF DUAL
Select the Tone Pitch control for the received audio.
F 3 AF PITCH
Enable/Disable the Volume Setting Alert feature.
F 4 AF PREST
Select the DIAL knob and display function.
F 5 AF-VFO
Enables/Disables the beeper.
F 6 BEEP
Enable/Disable the battery saver of the optional BH-1 Bluetooth
F 7 BLU SAVE
Enables/Disables the Bluetooth
F 8 BLU VOX
Activates/Disables the Internal Clock/Stop Watch Timer.
F 9 CLOCK
Activates the Club Channel Monitor.
F10 CLUB PRI
Indicates the DC Supply Voltage.
F11 DC VOLT
Setting of the display's illumination level.
F12 DIMMER
Programming of the DTMF Autodialer.
F13 DTMF
Selects the category which is recalled from the top panel
F14 FKEY MOD
Assigns a function to the Function Key.
F15 FKEY SEL
Programming a Member List for the Message feature.
F16 ID LIST
Sets your Personal ID for the Message feature.
F17 ID REG
Programming a Message for the Message feature.
F18 MESSAGE
Adjust the microphone gain level.
F19 MIC GAIN
Select the function of the microphone's [ PGM ] key.
F20 MIC PRGM
Enables/Disables the Enhanced CTCSS Paging & Code Squelch function.
F21 PAGER
Enables/Disables the locking of the PTT key when the LOCK mode is activated.
F22 PTT LOCK
Selects the PTT key function.
F23 PTT MODE
Enables/Disables the Automatic Repeater Shift function.
F24 RPT ARS
Sets the Repeater Shift Direction.
F25 RPT MODE
Sets the magnitude of the repeater Shift.
F26 RPT SFT
Enables/Disables the band expansion.
F27 RX EXP
Shifting of the CPU clock frequency.
F28 RX F CCL
F29 RX M MOD Selects the receiving mode.
Selects the Scan range.
F30 SCN CVRG
Select the Scan type.
F31 SCN DRCT
F32 SCN MODE Selects the Scan Resume mode.
Select the scan start direction which initiates the scanner using the scan command.
F33 SCN STRT
Select the Speaker to be used.
F34 SPEAKER
Selects the number of CTCSS/DCS/EPCS Bell ringer repetitions.
F35 SQL BELL
Setting of the DCS code.
F36 SQL DCS
Enables/Disables split CTCSS/DCS coding.
F37 SQL EXP
Set the squelch threshold level.
F38 SQL LEVL
Setting of the CTCSS Tone Frequency.
F39 SQL TSQF
Selects the Tone Encoder and/or Decoder mode.
F40 SQL TYPE
Setting of the synthesizer steps.
F41 STEP
Select the audio output.
F42 STEREO
Setting of the TOT time.
F43 TOT
F44 TX POWER Selects the transmit power output level.
F45 VOL.ITCOM Sets the volume level of the intercom mode.
Enables/Disables VOX operation.
F46 VOX MIC
Sets the VOX sensitivity.
F47 VOX SENS
Enable/Disable the Internet Connection feature.
F48 WIRES
Enables/Disables the Weather Alert Scan feature.
F49 WX ALERT

Menu Mode

Function
® function (requires the optional BU-1 Bluetooth
E H 0 2 7 M
®
/
4 0 1
Page
56
25, 62
85
86
57
77
Headset. 61
® Unit). 61
53
44
83
94
71
key. 94
77
47
49
46
87
79
66
87
77
74
73
73
74
96
76
80
81
80
81
86
82
65
82
98
64
64, 65
76
87
58
99
100
57
58
68
100
