The Menu mode's various selections and parameters can be displayed on the external monitor. For details on
menu operation, please see the discussion below.
Entering the Menu Mode
1. If you press and hold in the [ ENT ] key for more
than two seconds, white letters will appear at the
bottom of the screen to indicate various functions,
and the [ BAND ] keys will act as "Function" keys.
If you once more press and hold in the [ ENT ] key
for at least two seconds, the white-lettered tabs
will disappear, and control of the various func-
tions will be cut off; the [ BAND ] keys will no longer
act as "Function" keys.
2. Press the [ MNU ] key momentarily. The Menu list
will appear on the after-market monitor, and you
will see the Menu Number, Menu Groups, Menu
Items, and the current settings for each item dis-
play on the monitor.
3. Rotate the [ Main Tuning Dial ] knob to select the
Menu item you wish to work on.
4. Rotate the [ CLAR/VFO-B ] knob to change the
current setting of the selected Menu item.
5. When you have completed the changes to the
Menu item(s), press and hold in the [ MNU ] key
for 2 seconds; the setting(s) will now be saved.
If you do not want to save the new setting, press
the [ MNU ] key momentarily; the radio will revert
to its previous condition.
Page 4
E
SING AN
A M
BOUT ENU
FT 9000MP/C
DX ONTEST
M
XTERNAL
M O
ODE PERATION
D M
ATA ANAGEMENT
ONITOR
Function keys (BAND keys)
[1/1.8] ~ [8/21] keys
[ENT] key
MNU key
MAIN Tuning knob
CLAR/VFO-B knob
