Kuryakyn 9128 Installation Manual

chrome rear master cylInder covers 9128
fI ts a l l '99- uP tour I ng model s ( dresser , road kIng , road gl Ide, street
glId e , etc .) an d al l '00-uP softaIl model s.
Parts Included
1 Chrome Master Cylinder Cover with Sight Lens
1 Hardware Kit for Master Cylinder Cover Including:
2 Stand-off Stud
2 8-32 X 5/16" Button Head Cap Screw
1 Installation Instructions
Please read and understand entire instructions before starting installation.
thank you for choosIng küryakyn!
Please note
It is the installers' responsibility to make sure all fasteners (including pre-assembled) are
tightened before operation of motorcycle. Küryakyn will not warranty components that are
lost due to improper installation. Periodic maintenance may be required.
tools suggested
Phillips Screw Driver and a 5/16" Combination Wrench, Allen Wrenches
CAUTION
DOT 5 brake fluid is silicone based and normally not harmful to paint, it is a good idea to
clean up any spills immediately just in case another type of brake fluid was used in a previous
service.
Procedure
steP 1 Remove the two Phillips screws that fasten the reservoir top cover in place. (This is
a good time to check your brake fluid level.)
steP 2 Replace the stock Phillips screws with the stand-off studs included with this kit.
Tighten securely but do not over tighten.
steP 3 Set the cover in place over the master cylinder reservoir with the cut out along the
bottom edge towards the inside.
steP 4 Secure the cover in place using the included
8–32 X 5/16" button head cap screws.
Ride On!
9128-13HD-0906
I N S TA L L AT I O N
Installed
