Wheel Well Guard
Driver's Side (1)
TOOLS REQUIRED:
•
Phillips Head Screwdriver
•
T-15 Torx bit / Driver
C
B
A
Wheel Well Guards
79031 - Installation Instructions
PACKAGE CONTENTS:
Supplied Hardware
for Work Truck Models
12 - #10 SEM Screws
12 - U-Clips
Your vehicle's rear fender wells should be
cleaned prior to the installation of your
new Husky Wheel Well Guards.
E
Read all directions thoroughly prior to the
D
F
A, B, C, D, E and F are pre-drilled fastener
1. Check part number on the top of the Wheel
•
•
Page 1
GMC Sierra
Wheel Well Guard
Passenger's Side (1)
VEHICLE PREPARATION:
Installation
installation of your Wheel Well Guards.
locations for installation.
Well Guard and identify DS & PS to determine
which side to install.
7903 DS installs on the driver's side.
7903 PS installs on the passenger's side.
7903INS_R1
Advertisement
Related Manuals for HUSKY LINERS 79031
Summary of Contents for HUSKY LINERS 79031
- Page 1 Wheel Well Guards 79031 - Installation Instructions GMC Sierra PACKAGE CONTENTS: Supplied Hardware for Work Truck Models 12 - #10 SEM Screws 12 - U-Clips Wheel Well Guard Wheel Well Guard Driver’s Side (1) Passenger’s Side (1) TOOLS REQUIRED: VEHICLE PREPARATION: •...
- Page 2 2. Remove the factory Torx head screws that hold the factory carpeted wheel well liner in place and remove the factory wheel well liner. Note: If your Sierra was not equipped with fac- tory wheel well liners skip to step 3. 3.
- Page 3 6. Insert the lower flap sections of the Wheel Well Guard into the fender well behind the fender well lip. Perform this step for both the front and rear lower flap sections. Well Guard lip is tucked behind the metal fender well lip of the truck 7.
- Page 4 11. Repeat steps 1-10 on the opposite side. Congratulations, You have now successfully installed your new Husky Liners Wheel Well Guards. If you have any questions please call us at 1-800-344-8759. HUSKY LINERS WHEEL WELL GUARDS LIMITED LIFETIME...
