convenience concepts 131566 Assembly Instructions

Designs 2 go monterey square coffee table

Download this manual

DESIGNS 2 GO MONTEREY SQUARE

ASSEMBLY INSTRUCTIONS

We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,

step by step instructions will guide you through the project from start to finish .

Feel confident that this will be a fun and rewarding project . The final product will be a quality

piece of furniture that will go together smoothly and give years of enjoyment .

Please do not return to the store

STOP

Broken or missing parts?

Need help with assembly?

Our Illinois based customer service team is ready to help with any problems or questions you may have.

Please give us a call (Toll Free) at 1-800-468-6447, or email us at parts@convenience-concepts.com.

Normal hours of Operation: M-F* 8am-4pm CST.

*Excludes Holidays

This product's warranty is only valid through authorized dealers.

COFFEE TABLE

131566

Need help?

Do you have a question about the 131566 and is the answer not in the manual?

Page 1 DESIGNS 2 GO MONTEREY SQUARE COFFEE TABLE 131566 ASSEMBLY INSTRUCTIONS We have designed our furniture with you , the customer in mind . Our clear , easy to follow , step by step instructions will guide you through the project from start to finish .
Page 2 Hardware List Glue (1pc) Glue : For securing please apply to Screw (16pc) Wood Dowel (16pcs) CamBolt ( 12pcs ) Cam Lock wood dowel ﬁrst before inserting (12pc) into panel . Panel List *Please count and verify all parts before assembly .* Top panel Left Frame Support Bar...
Page 3 Step 1 *Assemble unit on carpet or ﬂat surface. 1.Connect Support Bars to Top Panel using Screws (D) as shown. 2.Connect Support Bars to Bottom Panel using Screws (D) as shown. Step 2 *Assemble unit on carpet or ﬂat surface. 1.Insert Cam Locks (C) and Wood Dowels (A) into Top Panel and Bottom Panel 2.Screw Cam Bolts (B) into...
Page 4 Step 3 1.Insert Cam Locks (C) and Wood Dowels (A) into Top Panel and Bottom Panel 2.Screw Cam Bolts (B) into Left Frame 3.Connect Left Frame to unit by gently tightening Cam Locks (C). Step 4 1.Enjoy. Page 4 of 4...
