Gotrax ECLIPSE User Manual

Gotrax ECLIPSE User Manual

Hide thumbs Also See for ECLIPSE:

Advertisement

Quick Links

Download this manual
E C LIP SE

Advertisement

loading
Need help?

Need help?

Do you have a question about the ECLIPSE and is the answer not in the manual?

Questions and answers

Related Manuals for Gotrax ECLIPSE

Summary of Contents for Gotrax ECLIPSE

  • Page 1 E C LIP SE...
  • Page 6 264 lbs (120kg) 20 mph (32 km/h).
  • Page 8 20 mph 25-28 miles 264 lbs (120kg) 36V 12Ah DC 42V 2.0A About 6-7 hours 500W AC 100-240V~50/60Hz 2.5A...
  • Page 9 Lift the tiller upright (as shown in the gure). Once the scooter is locked in the upright position, verify by gently trying to fold.
  • Page 10 About 6-7 hours.
  • Page 11 On/OFF machine: Long press 3 seconds the power button to turn on/o , the buzzer will “di” sound, and the scooter will shut down automatically after 5 minutes without any oration. Shift gears: Press the power button to change gears. The speed is 0-3 MPH in pedestrian mode in 1st gear ( ), 0-15.5 MPH in icon speed in 2nd gear (D), and 0-20 MPH in icon speed in 3rd gear (S).
  • Page 12 2. Turn it on again with password status, enter the correct password and press the power button 4 times within 10 seconds to enter the password change mode , on the change password mode even 4 times the power button, or 1 minutes without any operation , the new password will not saved and exit the mode , even in cipher amending mode according to the power button twice, save the modi ed password and exit the mode.
  • Page 13 8. Brake Light Status: The taillights is also the brake light. When you turn on the headlight, the brake light will steady on. When you hold the handlebrake, The taillights will be highly bright, reminding the vehicles and pedestrians behind.
  • Page 16 Tightening the Tiller: If you notice that the tiller is loose or wiggles while riding, you can tighten the screws. Open the plastic cover, and use the Allen wrench to tighten the screws as shown in the gure below. (Figure 1) Brake adjustment: If the brake is too tight against the brake, turn the brake cable nut counterclockwise to loosen the brake cable, if the brake is too loose, turn the brake wcable nut clockwise to tighten the brake cable.
