GETTING STARTED
BEFORE YOU BEGIN
•
Make sure the type of paint you use can be cleaned
with either mineral spirits (for oil-based paints) or
a warm water and soap solution (for latex paints).
•
It is a good idea to have drop cloths protecting your
floors and anything else in the room that you do
not want accidentally splattered with paint.
PARTS AND COMPONENTS
Outer cap
Roller
cover
Inner cap
Roller arm
assembly
FILLING THE MAIN TUBE
The
EZ-Roller™
i
preassembled new, or should
already
Cleanup during previous usage.
If the unit is not assembled, follow
the "Lubricating the Components"
steps on page 6.
1.
Apply a thin layer of petroleum jelly to the fill
tube. This will help the fill valve slide easily off the
fill tube.
2.
Clip fill tube to paint container.
3.
Press down and firmly hold the fill valve onto the
fill tube.
4.
Pull the plunger to draw the material into the main tube. When the tube is full, you are ready to begin
using the EZ-Roller™.
2
EN
Inner spacer
Quick-release tab
Head Main tube
should
come
be
assembled
after
Attention
Fill valve
1
3
Some oil-based paints require a
stronger cleaning solution than
mineral spirits and should not be
used with the EZ-Roller™. Using
a cleaning solution stronger
than mineral spirits may cause
damage to the EZ-Roller™.
Check with your paint supplier to
be sure the oil-based paint you
have can be cleaned with mineral
spirits.
Fill tube
Locking collar
Trigger
2
4
Plunger
Advertisement
Related Manuals for WAGNER Spraytech 2419329
Summary of Contents for WAGNER Spraytech 2419329
- Page 1 GETTING STARTED Some oil-based paints require a BEFORE YOU BEGIN stronger cleaning solution than • Make sure the type of paint you use can be cleaned mineral spirits and should not be used with the EZ-Roller™. Using with either mineral spirits (for oil-based paints) or Attention a warm water and soap solution (for latex paints).
- Page 2 USAGE GENERAL ROLLING TIPS • PREPARING THE ROOM Be careful not to over-saturate the roller cover as it may drip, slide on the wall or spatter. Remove all pictures, mirrors, and decorations from • Make sure to run the roller cover over the areas the walls and draperies from the windows.
- Page 3 CLEANUP BEFORE YOU BEGIN CLEANING • If you used water-based materials (latex), use warm, soapy water to clean the EZ-Roller™. • If you used oil-based materials, use mineral spirits. YOU WILL NEED • A large bucket or other container that will hold cleaning solution.
- Page 4 Unclip fill tube from container, but keep installed into the fill valve. Submerge the fill tube into the appropriate cleaning solution and pull the plunger in and out a minimum of 5 times. Remove the fill tube. Submerge the fill valve and roller arm and pull the plunger in and out a minimum of 5 times.
