Carson MM-24 Manual

20-40X ZOOM MICROSCOPE
CD
Eyepiece
Q) Zoom Wheel
@
LED On/Off Button
@)
Focusing Lever
®
Battery Insulate
®
Specimen Stage
(J)
Battery Door
®
Battery Door Screw
® Specimen Slides Covers
® Specimen Slide
5
®
HOWTOUSE
Getting Ready
Remove the Battery Insulate ( 5) by pulling
it outward.
Observing with Specimen Stage (6)
1. Place the object of observation onto the
Specimen Slide (10) and place a Specimen
Slide Cover (9) on top of the object.
Insert the Specimen Slide into the
Specimen Stage.
2. Place the Microscope into the Specimen
Stage and press the LED On/Off Button
(3) and observe through the Eyepiece ( 1) .
3. Turn the Zoom Wheel to adjust the desired
degree of magnification ( from 20X to 40X) .
4. Slide the Focusing Lever (4) gradually until
the image is clear and sharp.
Observing without Specimen Stage
1. Place the microscope directly on top of the
object of observation and press the LED
On/Off Button and observe through the
E yepiece.
2. Turn the Zoom W heel to adjust the desired
degree of magnification { from 20X to 40X) .
3. Slide the Focusing Lever (4) gradually until
the image is clear and sharp.
BATTERY INSTALLATION
➔
➔
> >
If the LED light becomes dim , it means that it's time to replace the batteries.
1. Unscrew the Battery Door Screw (8) w ith a screwdriver and remov e the Battery Door (7) in the direction
shown by the arrow .
2. Remov e the used-up batteries and insert 3 pcs of fresh LR44 button cells into the battery compartment
in the right polarity.
3. Close the Battery Door and tighten the Battery Door Screw w ith a screwdriver.
