Chorus/Mod Effects

The Modulation Effects row is a multi-function module allowing you to select effects such as; Chorus, Flanger, Phaser,
Triggered Flanger,Triggered Phaser,Tremolo, Panner,Vibrato, Rotary Speaker, AutoYa™, YaYa™, SynthTalk™, Envelope
Filter (auto wah), Detune, and Pitch Shift. Only one of the effects in this row can be used at a time.When the
Chorus/Mod row is selected, the Status button is used to turn the Effect module on (EFF ON) and off (EFFOFF).The
Number 1 Knob is used select the type of Effect to be used. After selecting the type of effect in this module, the
Number 2, Number 3, Number 4, and Number 5 Knobs can then be used to adjust the individual Parameters
associated with the selected effect.The following pages describe each Effect and their Parameters in more detail.
Chorus (CHORUS)
A Chorus adds a short delay to your signal.The delayed signal is modulated in and out of tune and then mixed back
with the original signal to create a thicker sound.
Parameter 1 - The Number 2 Knob adjusts the rate (SPEED) of the modulation. Ranges from 1 to 99.
Parameter 2 - The Number 3 Knob adjusts the intensity (DEPTH) of the modulation. Ranges from 1 to 99.
Parameter 3 - The Number 4 Knob adjusts the PreDelay (PREDLY) or length of time before the Chorus effect
is applied to the input signal. Ranges from 1 to 20.
* Parameter 4 - Selects the waveform used by the Chorus.Waveforms include Triangle, Sine, and Square.
* Parameter 5 - Adjusts the left to right balance of the wet signal. Ranges from L 99 to R 99.
Mod Level - The Number 5 Knob controls the volume of the Chorus. Ranges from 0 to 99.
Flange (FLaNge)
A Flanger uses the same principle as a Chorus but uses a shorter delay time and adds regeneration (or repeats) to
the modulating delay.This results in an exaggerated up and down sweeping motion to the effect.
Parameter 1 - The Number 2 Knob adjusts the rate (SPEED) of the modulation. Ranges from 1 to 99.
Parameter 2 - The Number 3 Knob adjusts the intensity (DEPTH) of the Modulation. Ranges from 1 to 99.
Parameter 3 - The Number 4 Knob adjusts the amount of feedback (REGEN) added to the Flanger delay. Ranges
from 0 to 99.
* Parameter 4 - Selects the waveform used by the Flanger.Waveforms include Triangle, Sine, and Square.
* Parameter 5 - Adjusts the left to right balance of the wet signal. Ranges from L 99 to R 99.
Mod Mix - The Number 5 Knob controls the mix of wet and dry signal. Ranges from 0 (all dry) to 99 (all wet).
Phaser (PHaseR)
A Phaser splits the incoming signal, and then changes the phasing of the signal.This signal is then taken in and out of
phase and mixed back in with the original signal. As the phasing changes, different frequencies get canceled resulting
in a warm sort of twisting sound.
Parameter 1 - The Number 2 Knob adjusts the rate (SPEED) of the modulating phase. Ranges from 1 to 99.
Parameter 2 - The Number 3 Knob adjusts the intensity (DEPTH) of the modulation. Ranges from 1 to 99.
Parameter 3 - The Number 4 Knob adjusts the amount of effected signal returned to the input of the Phaser
(REGEN). Ranges from 0 to 99.
* Parameter 4 - Selects the waveform used by the Phaser.Waveforms include Triangle, Sine, and Square.
* Parameter 5 - Adjusts the left to right balance of the wet signal. Ranges from L 99 to R 99.
Mod Mix - The Number 5 Knob controls the mix of wet and dry signal. Ranges from 0 (all dry) to 99 (all wet).
Triggered Flanger (TRGFLG)
A Triggered Flanger is the same sound as a regular Flanger but allows you to choose the starting point of the
Flanger sweep. In a regular Flanger, the low frequency oscillator (LFO) is continually sweeping up and down.This
means that when you begin to play, the flanger may be at the top, bottom, or any random point of the sweep.With a
Triggered Flanger, every time the signal exceeds the Sensitivity level setting, the Flanger will begin at the point of the
sweep that you designate with the value of the LFO Start Parameter.
Parameter 1 - The Number 2 Knob adjusts the rate (SPEED) of the modulation. Ranges from 1 to 99.
Parameter 2 - The Number 3 Knob adjusts the strength the signal must be (SENSTV) in order to trigger the
Flanger. Ranges from 1 (requiring strong signals to trigger) to 99 (triggers with weak signals).
Parameter 3 - The Number 4 Knob selects the Flanger sweep starting point (LFO ST). Ranges from 0 to 99.
Mod Mix - The Number 5 Knob controls the mix of wet and dry signal. Ranges from 0 (all dry) to 99 (all wet).
* These Parameters are only available using the G
S T - E
ECTION HREE
N ™ computer editor software.
