Delta UH3000 Assembly Instructions

Single Hook
Utility Holder
Assembly instructions
Position product as desired and use as a
1
template for marking holes to be drilled.
Drill holes into center of wooden wall
2
stud to accept screws.
IMPORTANT SAFETY NOTE
Mount securely into wall stud or solid
wall using appropriate wall anchors.
If in doubt, seek expert advice.
Tools Required
Hand Drill 1/8"(3mm)
WARNING
Do not exceed maximum total weight limit of 22kg/50lbs. Incorrect wall mounting could result in items falling and
injury to persons. Avoid mounting in a position where personal injury could result from walking into protruding rack.
UH3000
STUD
WALLBOARD
STUD
CENTERLINE
