Kemimoto B1406-04101BK Product Manual

BEFORE YOU BEGIN
1. Read these instructions and check to be sure all parts and
tools are accounted for.
2. Please retain these installation instructions for future
reference and parts ordering information.
PRODUCT INFORMATION
1
FUNCTION
01
A
Loosen four screws [A], the two metal plates can be
adjusted left and right.
INSTALLATION TIPS
STEP 1
2
5
6
4
3
Install two metal brackets [2] to the mirror [1] with
parts [3,4,5,6].
K www.kemimoto.com K
PRODUCT MANUAL
SKU: B1406-04101BK
2
6
A
You can choose which hole
to secure the mirror [1]
based on your need.
Designed by Kemimoto Group
Complete journey of dreams
IMPORTANT
1. Please read the installation instructions carefully before you start.
2. If the vehicle is clean and free of other debris, it will be easy to install.
3. For your safety and to ensure a satisfactory installation, please
complete all the installation steps in the order shown below.
3 4
7 8
02
3
Loosen two thumb screws [3], the mirror [1] can be swung
up and down 180°.
STEP 2
the front inner
side of the roof panel
1
Place the metal brackets [2] against
the front inner side of the roof panel,
secure them with four self-tapping
screws [7].
1 of 1
K Kemimoto All Rights Reserved,Infringement must be prosecuted.
1
Center Mirror
2
Metal Bracket
3
Thumb Screw
4
Metal Washer
5
5
Rubber Washer
6
Lock Nut
Self-tapping Screw
7
8 Allen Wrench
9
9
Open End Wrench
180°
2
x1
x2
x2
x2
x2
x2
x4
x1
x1
2
7
