Kemimoto B1406-04401BK Product Manual

BEFORE YOU BEGIN
1. Please read the instructions carefully and verify that each item is in the list.
2. Please retain these installation instructions for further reference and parts ordering information.
IMPORTANT
1. Please read the installation instructions carefully before you start.
2. If the vehicle is clean and free of other debris, it will be easy to install.
3. For your safety and to ensure a satisfactory installation, please complete all the installation steps in the order shown
below.
PRODUCT INFORMATION
R1
3
5
1
L1
2
14
K www.kemimoto.com K
PRODUCT MANUAL
SKU: B1406-04401BK
R2
R2
10
15
16
L2
L2
4
17
17
18
Designed by Kemimoto Group
Complete journey of dreams
R3
R3
L3
6
11
1 of 4
K 2023 Kemimoto All Rights Reserved,Infringement must be prosecuted.
R4
8
9
12
15
13
17
7
17
L3
1
Front Bracket x1
2
Left Front Splice Pipe x1
3
Right Front Splice Pipe x1
4
Left Front Bracket x1
5
Right Front Bracket x1
6
Middle Splice Pipe x2
7
Left Rear Splice Pipe x1
8
Right Rear Splice Pipe x1
9
Rear Bracket x1
10
Roof Support Pipe x3
11
T-shaped Fixture x6
12
Rear Storage Bracket x1
13
Rear Fixed Bracket x2
14
ST5*12 Self-tapping Screw x8
15
M6*15 Bolt x10
16
M6*20 Bolt x12
17
M6*6 Nut x22
18
Roof Cover x1
L4
