Kemimoto B1406-02501 Product Manual

BEFORE YOU BEGIN
1. Read these instructions and check to be sure all parts and tools are accounted for.
2. Please retain these installation instructions for future reference and parts ordering information.
IMPORTANT
1. Please read the installation instructions carefully before you start.
2. If the vehicle is clean and free of other debris, it will be easy to install.
3. For your safety and to ensure a satisfactory installation, please complete all the installation steps in the order shown below.
PRODUCT INFORMATION
All light strips come with 9.8 ft wire
1
36 inch Light Strip
2
28 inch Light Strip
3
20 inch Light Strip
4
12 inch Light Strip
5
8 inch Light Strip
6
Control Box
7
Cable Tie
8
Light Strip Clip
9
Self-tapping Screw
10
Adhesive for Control Box L65xW25xH2mm
11
Controller
INSTALLATION TIPS
6
9
8
9
K www.kemimoto.com
PRODUCT MANUAL
SKU: B1406-02501
x2
x2
x2
x4
x2
x1
x24
x24
x52
x1
x1
10
(Black)
PRORGB CONTROLLER
(Red)
K Designed by Kemimoto Group
Complete journey of dreams
2
1 3
6
7
Recommended Installation Location of Light Strips
Left and Right Sides of
Vehicle Roof: 36 inch [1]
Inner side of Center Console:
Wheel Well: 8 inch [5]
12 inch [4]
1 of 1
K Kemimoto All Rights Reserved,Infringement must be prosecuted.
8
4 5
9
10
Front and Back Sides of
Vehicle Roof: 20 inch [3]
Side Skirt:
28 inch [2]
11
Inner side of
Wheel Well:
12 inch [4]
