Kemimoto B1406-05501SL Product Manual

BEFORE YOU BEGIN
1. Please read the instructions carefully and verify
that each item is in the list.
2. Please retain these installation instructions for
further reference and parts ordering information.
PRODUCT INFORMATION
Battery Holder B(R)
1
Battery Holder A
2
3 Battery Holder C
4 Battery Holder D
5 Battery Holder E
6 Battery Holder F
7
Battery Holder B(L)
8
M8x25mm Countersunk Hexagon Socket Screw
9
M8x30mm Countersunk Hexagon Socket Screw
10
M8 Flange Anti-loose Nut
11
M8x25mm External Hexagon Flange Face Bolt
12
M8 Hexagon Wrench
13
Open-end Wrench
INSTALLATION TIPS
STEP1:
Lift up the seat cushion to reveal the battery compartment.
Disconnect the power and remove the battery, placing it aside.
a
b
K www.kemimoto.com K
PRODUCT MANUAL
SKU: B1406-05501SL
x1
x2
x1
x1
x1
x2
x1
x8
x4
x16
x4
x1
x2
Remove
a
b
c
c
Original Battery Bracket B
Designed by Kemimoto Group
Complete journey of dreams
IMPORTANT
1. Please read the installation instructions carefully before you start.
2. If the vehicle is clean and free of other debris, it will be easy to install.
3. For your safety and to ensure a satisfactory installation, please
complete all the installation steps in the order shown below.
2
1
6
Original Battery
Bracket A
STEP2:
Use a cutting machine to saw off the original battery
bracket [A], and grind the welding marks smooth (pay attention to
safe operation).
a
Original Battery Bracket B
STEP3:
Loosen the original screws at [a], remove the original
screws at [b] and [c] (keep them aside), and remove the original
battery bracket B.
1 of 3
K 2023 Kemimoto All Rights Reserved,Infringement must be prosecuted.
Estimated
installation
time:
20 minutes
8
2
3
4
7
5
6
Original Battery Bracket B
Remove
b
c
Remove
9
10
11
12
13
