Arkon MG279 Manual

SM427 | Bicycle Handlebar Mount with Universal Holder
TAB179 | Universal Tablet Multi-Surface Car & Desktop Mount
MG279 | Mobile Grip 2 Deluxe Mini Windshield or Dashboard Sticky Suction Mount
GN079
*If the sticky suction base becomes dirty or loses stickiness,
rinse under warm water with mild liquid soap and let air dry.
1
Attach pedestal to dash or windshield, engage suction lock.
Push down on
suction base
IMPORTANT: With certain dashboard surfaces you may
need to push down firmly on the suction base while
engaging the suction lock lever to create enough suction
to hold the mount.
3
Insert device and tighten ring to set position.
!
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsibility
of liability for injury or death as a result of car crashes and / or air bag
deployment.
Arkon is not responsible for any damages caused to your vehicle, your
device, or yourself due to the installation or use of this mount.
MG002
AP013
Suction Lock
Lever
Package Contents:
(1) MG002 – Mobile Grip 2 Universal Smartphone Holder
(1) GN079 – Multi-Surface Sticky Suction Mounting Pedestal
(1) AP013 – 80mm Adhesive Disk
(1) SP-SB-RING - Swivel Adjustment Ring
DASHBOARD MOUNTING WARNING: THE STICKY SUCTION PEDESTAL SHOULD NOT BE USED ON SOME
SP-SB-RING
TYPES OF DASHBOARDS. IT MAY LEAVE A PERMANENT INDENTATION ON DASHBOARD SURFACES MADE
OF SOFT VINYL, LEATHER, OR SIMILAR MATERIALS. TO PREVENT PERMANENT INDENTATION MARKS,
USE THE INCLUDED ADHESIVE MOUNTING DISK WHEN MOUNTING ON SOFT DASHBOARD SURFACES.
IMPORTANT: Some dashboards with heavily textured or porous surfaces may require you to push
down on the suction base while engaging the suction lock lever to achieve the suction required to
hold the mount in place.
2
Place adjustment ring over the pedestal ball and snap Mobile Grip
2 Universal Holder onto the pedestal.
OPTIONAL: For use on soft vinyl or leather dashboards, use included
adhesive mounting disk*.
*Let mounting disk adhesive cure for 24 hours before use.
Consumer Hotline:
(800) 841-0884
USA
INT'L (626) 254-9005
Monday - Friday 9am - 5pm, PST
Adjustment Ring
Adhesive Mounting
Disk*
The Mobile Mounting Specialists™
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2018 Arkon Resources, Inc.
rev.032018
