XtremeAIR PRO-X Series Installation & User Manual
Under cabinet
Hide thumbs
Also See for PRO-X Series:
- Installation manual & user manual (14 pages) ,
- Installation & user manual (12 pages) ,
- Installation manual & user manual (9 pages)
Related Manuals for XtremeAIR PRO-X Series
Summary of Contents for XtremeAIR PRO-X Series
- Page 1 THE ADVANCED RANGE HOODS PRO-X SERIES | ULTRA SERIES | SPECIAL ULTRA SERIES| ECONOMY SERIES INSTALLATION & USER MANUAL FOR UNDER CABINET RANGE HOODS XtremeAIRusa.com 04.28.25 | 1...
-
Page 2: Need Assistance
Please exercise extreme caution at all times. If you have any questions or encounter any issues you do not fully understand, contact the XtremeAIR USA Customer Support Team at 714.554.9000 or email us at Support@XtremeAIRusa.com. - Page 3 MOUNTING HEIGHT & VENTING METHODS MOUNTING HEIGHT FOR THE MOST EFFICIENT & QUIET OPERATION, a distance of 26” to 30” is recommended between stove top and the bottom of range hood. If the hood is mounted too low this could result in heat and/or fire hazard. If the hood is mounted too high the controls will be hard to reach and the hood will lose its performance and efficiency.
- Page 4 PREPARATION IMPORTANT: Observe all governing building codes and city ordinances. A 120 volt, 60 Hz. AC, 15-amp outlet is needed (fused electrical circuit is required). It is the customer’s responsibility to contact a qualified electrical installer, and assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 —...
-
Page 5: Installation
INSTALLATION STEP 1: CREATE WORK STATION Creating a work station is optional. Otherwise, Place 2 pieces of wood about 2” x 4” x 20” on both sides of stove & a plywood plank on top of them to cover range with a thick protect cook top or stove from damage or dirt. - Page 6 INSTALLATION STEP 6A: SECURE HOOD TO BOTTOM CABINET From inside of the hood, using the hex bit extension, place one screw (provided) into each key hole or pre-drilled holes (fig. A) and secure to cabinet Top View of Range Hood bottom.
- Page 7 PANEL CONTROL GUIDE DIGITALTOUCH PANEL HAND GESTURE ADJUST LIGHT DECREASE INCREASE POWER TOGGLE CLOCK/TIMER TOGGLE CONTROL CONTROL (on select models) ACTIVE FAN ACTIVE TIMER ACTIVE LIGHTING GESTURE SENSING INDICATOR INDICATOR INDICATOR INDICATOR Clock & Delay Timer Clock Button & Delay Timer Button: Set the clock: Touch the clock symbol with the fan off. The time on the display will blink.
-
Page 8: Light Bulb Replacement
LIGHT BULB REPLACEMENT GU-10 LIGHT BASE Slightly press inward Keep your thumb grip Pull the bulb straight Align the new light Press the new bulb on the GU10 bulb using and pressure constant out of the socket bulb’s legs with the 2 inward into the socket, both thumbs as you turn the bulb... -
Page 9: Care And Maintenance
CARE & MAINTENANCE Operation Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers, and loose clothing. NEVER dispose of cigarette ashes, ignitable substances, or any foreign objects into blowers. -
Page 10: Limited Warranty
XtremeAIR product. This Limited Warranty does not cover XtremeAIR products sold AS IS or WITH ALL FAULTS, light bulbs, remote control, normal maintenance and service, costs of removal or installation. This Limited Warranty is invalid if the factory-applied serial number has been altered or removed from the product.
